LS300-INS-LAB-RevD19
9
5 SETUP
WARNING: Always use a standard healthcare bed frame with appropriate safeguards and
protocols. Frame and side rails must be properly sized relative to the mattress to help
minimizeanygapsthatmightentrapapatient’sheadorbody.
MATTRESS INSTALLATION
1. Ensure bed is level and brakes are locked.
2. Remove existing mattress from bed frame.
3. Replace the mattress with the mattress replacement system. Orient mattress so that the air
tube is at the foot of the bed.
If re-installing the Select Mattress System onto a new frame or for a new patient, check
mattress surface for staining and soiling; clean and / or disinfect as required (see
CARE AND MAINTENANCE section).
4. Ensure mattress is properly positioned with no gaps between mattress and bed frame or side
rails.
5. Secure straps on bottom of mattress to the bed frame.
PUMP INSTALLATION
Power SwitchHanger
Pump Rear View Pump Front Panel
1. Place pump on a horizontal surface or hang the pump on the foot board of the bed frame with
built-in hanger on back of pump.
2. Connect pump hoses to mattress — attach the air tube connectors
to the socket on the right pump front panel as shown at right.
Ensure air hoses are not kinked and will not be pinched by any
articulated bed mechanisms.
3. Attach cover to mattress.
4. Ensure POWER switch is in the OFF position.
5. Plug pump into a properly grounded wall outlet; ensure power to this outlet is not controlled
by a wall switch. The unit will turn on initiating compression, then turn off.
To Next Page
