Gram K3 SERIES User Manual

35
The status byte is built from the binary values of the display indications (tare, zero,
gross/net and stability). 20h is added to the result to ensure that the result is
printable.
Bit 0 (01h) The transmitted value is the gross weight.
Bit 1 (02h) A tare is set.
Bit 2 Not used, always 0.
Bit 3 (08h) The indicator is set to zero.
Bit 4 Not used, always 0.
Bit 5 Not used, always 0.
Bit 6 (40h) The weight is stable.
Bit 7 Not used, always 0.
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
N/A
Stability
N/A
N/A
Zero
N/A
Tare
B / W
Examples:
The status byte is 61h (‘a‘)
61h – 20h = 41h
è
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(no zero)
Bit 2
Bit 1
(Tare off)
Bit 0
(Gross)
0
1
0
0
0
0
0
1
The status byte is 69h (‘i‘)
69h – 20h = 49h
è
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(zero)
Bit 2
Bit 1
(Tare off)
Bit 0
(Gross)
0
1
0
0
1
0
0
1
The status byte is 62h (‘b‘)
62h – 20h = 42h
è
Bit 7
Bit 6
(stable)
Bit 5
Bit 4
Bit 3
(no zero)
Bit 2
Bit 1
(Tare on)
Bit 0
(Net)
0
1
0
0
0
0
1
0
