4
Hardware Pack Parts List for Model CGI08ALP
* Two Batteries/AA included in the Hardware Pack.
PART # PART DESCRIPTION QTYPURPOSE OF PART
P06024006A Hardware Pack 1 For use in assembly (Grill and Range)
S112G04061 Phillips Head Screw 1/4"x3/8" 8 Install Cart Frames to Left / Right Bowl Panels
S162M04201 Hex Head Screw M4X20mm 2 Secure Faucet Washer and Faucet Bracket to Faucet
S233G04084 Wing Bolt 1/4"x1/2" 1 Secures Gas Tank to Tank Holder
P05515017L Wrench
1
Adjust level on Island Assembly Set
Already packed in the Faucet Assembly Kit Box
Already Installed on Tank Holder
Already packed in the Cooking Components Box
Phillips Head Screw 1/4"x3/8"
Qty. 8
Part # S112G04061
Wing Bolt 1/4"x1/2"
Qty. 1
Part # S233G04084
Hardware already installed on the Tank Holder
Wrench
Qty.1
Part # P05515017L
Already packed in the Cooking Components Box
• Always purchase the correct size and grade of battery most suitable for the intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure the batteries are installed correctly with regard to polarity (+ and -).
• Remove batteries from equipment which is not to be used for an extended period of time.
• Remove used batteries promptly.
CORRECT BATTERY USE
