Parts List for Model CGI08ALP Grill
KEY DESCRIPTION PART# QTY
1 Lid Assembly
P00147063A
1
2
Temperature Gauge
P00601071A
1
3
Lid Handle
P00205086B
1
4 Heat Insulating Spacer
P06801022A
2
5 Protective Pad P05518011 I 2
6 Cooking Rack/Secondary P01516004B 1
7 Cooking Grid, 13" P01604013B 2
8 Cooking Grid, 6.4" P01604031B 1
9 Burner/Main P02008032A 3
10 Infrared Burner Assembly P02005010A 1
11 Thermocouple P05305019A 1
12
Savor Plate
®
P01708033E 3
13
Savor Plate
®
Bracket, Front
P033280504 3
14
Savor Plate
®
Bracket, Rear
P033280514 3
15 Burner Bracket P02210034A 1
16 Back Burner Assembly P02007068A 1
17 Back Burner Electrode P02614025A 1
18 Back Burner Wind Shield P06906046B 1
19 Back Burner Orifice P06534005A 1
20
Refrigerator Bracket, Left P03329012D 1
21 Back Burner Thermocouple P05305022A 1
22 Back Burner Thermocouple Bracket P03328047C 1
23 Bowl Panel, Front P0073878KA 1
24 Burner Heat Shield P06906045A 1
25 Grease Tray Heat Shield P06904020C 1
26 Grease Tray Heat Shield, Lower P06903050M
1
27 Electric Wire Set P02615121A 1
28 Gas Collector Box with Electrode P02609010B 3
29 Gas Valve/Manifold Assembly Y0060571 1
30 Grease Draining Plate P06902006B
2
31 Lighting Stick P05507008A 1
32 Bowl Support Bracket, Left P01301006D 1
33 Bowl Support Bracket, Right P01302006D 1
34 Control Panel Extension P02909768S 1
35 Control Panel Upper
P02915061S
1
36 Control Panel P02915051S 1
37 Electric Ignitor, 6-port P02502265C 1
38 Control Knob Seat P03415014A 5
39 Control Knob P03429065V 3
40 Control Knob For Back Burner/Infrared Burner P03429075V 2
41 Control Knob Spring P05504021A 5
42 Name Plate P00407010D 1
43 Electric Ignitor Protector P05545002A 1
44 Grease Tray P02717454A 1
45 Grease Tray Handle P00213012B 1
46 Cart Panel, Top P07805002A 1
