Connecting DP750
To setup the DP750 Base Station, please follow the steps below:
Figure 3: DP750 Back View
You have two options for power and network connection of the base station: AC power or Power over
Ethernet (PoE).
Note: For better signal range, we recommend to install DP750 horizontally with LED side facing toward the
usage area. For example, if you just put it on a desk, the LED better face up, if you mount it on the ceiling,
it better LED face down, in both cases, it toward the space area.
Connecting via AC power
1. Connect the micro-USB connector into the related port on the base station and connect the other
end of the power adapter into an electrical power outlet.
2. Connect the supplied Ethernet cable between the Internet port on the base station and the Internet
port in your network or the switch/hub device port.
Connecting via PoE
To connect the base station using PoE, you need to connect the Ethernet cable provided (or 3rd party
network cable) between the Network Socket on the base station to Ethernet port of your PoE switch/hub.
