Grandstream Networks DP750 Administration Guide

P a g e | 74
DP750/DP720 Administration Guide
Version 1.0.11.4
cn sn description
Last Name Attribute
Defines last name attributes of each record to be returned in the LDAP search
result.
This field allows users to configure multiple space separated name attributes.
Example:
gn
cn sn description
Work Number
Attribute
Specifies which LDAP attribute represent the contact’s work number. Must be in
number attributes on LDAP server.
Home Number
Attribute
Specifies which LDAP attribute represent the contact’s home number. Must be in
number attributes on LDAP server.
Mobile Number
Attribute
Specifies which LDAP attribute represent the contact’s mobile number. Must be in
number attributes on LDAP server.
Max. Hits
Specifies maximum number of results to be returned by LDAP server. If set to 0,
server will return all search results. Valid range is 1 to 3000. Default is 500.
Search Timeout
Sets interval (in seconds) for the server to process the request and return search
results to the client. Default is 30 seconds.
Private Phonebook Settings
Phonebook Name
Defines private phonebook name.
Import XML
Phonebook
Upload: Uploads manually private XML phonebook file to the base station.
Delete: Clears private XML phonebook file in the base station
Export XML
Phonebook
Downloads private XML phonebook from the base station in .xml format.
Change Base Station Admin PIN code
For security reasons, advanced settings in DP750 base station cannot be accessed from DP720 handset
except if Admin PIN code is provided. By default, Admin PIN code is 0000.
We strongly recommend changing your Admin PIN code following below steps:
1. Access the Web GUI of your DP750 using the admin’s username and password. (Default username
and password is: admin/admin).
2. Press Login to access your settings.
