P a g e | 40
GXP21XX User Guide
Version 1.0.9.108
Up Navigation key. In idle screen, press to see the IP.
Configuration via Keypad
To configure the LCD menu using phone's keypad, follow the instructions below:
Enter MENU options. When the phone is in idle, press the round MENU button to enter the
configuration menu.
Navigate in the menu options. Press the arrow keys up/down/left/right to navigate in the menu options.
Enter/Confirm selection. Press the round MENU button or “Select” Softkey to enter the selected
option.
Exit. Press “Exit” Softkey to exit to the previous menu.
Return to Home page.
In the Main menu, press Home Softkey to return home screen.
In sub menu, press and hold “Exit” Softkey until Exit Softkey changes to Home Softkey, then release
the Softkey.
The phone automatically exits MENU mode with an incoming call, when the phone is off hook or the
MENU mode if left idle for more than 60 seconds.
When the phone is in idle, pressing the UP-navigation key can see phone’s IP address, IP setting, MAC
address and software address.
The MENU options are listed in the following table.
Table 14: Configuration Menu
Displays Local call logs:
All Calls/Answered Calls/Dialed Calls/Missed Calls/Transferred Calls
Displays account status, network status, software version number and Hardware
Account status.
Network status.
Press to enter the sub menu for MAC address, IP setting information
(DHCP/Static IP/PPPoE), IPv4 address, IPv6 address, Subnet Mask, Gateway
and DNS server.
System Information
Press to enter the sub menu for Hardware version, P/N number. Boot, Core,
Base, Prog version and IP Geographic Information.
