P a g e | 49

GXP21XX User Guide

Version 1.0.9.108

For example:

If the target IP address is 192.168.1.60 and the port is 5062 (i.e., 192.168.1.60:5062), input the following:

192*168*1*60#5062. The * key represents the dot (.), the # key represents colon (:). Wait for about 4

seconds and the phone will initiate the call.

Quick IP Call Mode:

The GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 also supports Quick IP Call mode. This enables

the phone to make direct IP calls using only the last few digits (last octet) of the target phone's IP address.

This is possible only if both phones are under the same LAN/VPN. This simulates a PBX function using the

CSMA/CD without a SIP server. Controlled static IP usage is recommended.

To enable Quick IP Call Mode, go to phone's Web GUISettingsCall Features, set "Use Quick IP Call

Mode" to "Yes". Clicking on "Save and Apply" on the bottom of Web GUI page to take the change. To make

Quick IP Call, take the phone off hook first. Then dial #xxx where x is 0-9 and xxx<255. Press # or SEND

and a direct IP call to aaa.bbb.ccc.XXX will be completed. "aaa.bbb.ccc" is from the local IP address

regardless of subnet mask. The number #xx or #x are also valid. The leading 0 is not required (but it's OK).

For example:

 192.168.0.2 calling 192.168.0.3 -- dial #3 followed by # or "SEND";

 192.168.0.2 calling 192.168.0.23 -- dial #23 followed by # "SEND";

 192.168.0.2 calling 192.168.0.123 -- dial #123 followed by # "SEND";

 192.168.0.2: dial #3 and #03 and #003 results in the same call -- call 192.168.0.3.

Note:

 The # will represent colon ":" in direct IP call rather than SEND key as in normal phone call;

 If you have a SIP server, configured, direct IP call still works. If you are using STUN, direct IP call will

also use STUN;

 Configure the "User Random Port" to "No" when completing direct IP calls.

Virtual Multi-Purpose Keys

Web UI Configuration

Users can find new Virtual Multi-Purpose Keys (VPK) configuration under phone’s web

UISettingsProgrammable KeysVirtual Multi-Purpose Keys tab. It is recommended to select “Reset”

on this page before configuring VPK here. By default, all fixed VPKs are listed.
