P a g e | 29
HT813 Administration Guide
Version 1.0.1.2
Default value is 100. The last segment of IP address assigned to the HT813 in the LAN
Network.
Default configuration assigns IP address (to local network devices) starting from
192.168.2.100.
Default value is 199. This parameter allows a user to limit the number of local network
devices connected to the internal router.
Default configuration assigns IP address (to devices connected to the LAN port) in a
range from 192.168.2.100 up to 192.168.2.199.
Sets the LAN subnet mask.
Default value is 255.255.255.0
Default value is 120 hrs (5 days). The length of time the IP address is assigned to the
LAN clients. Value is set in units of hours.
This function forwards all WAN IP traffic to a specific IP address if no matching port is
used by HT813 or in the defined port forwarding.
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific
(TCP/UDP) port. Up to 8 rules are available.
Gives the administrator the option to restore default configuration on the HT813.
There are 3 types of factory reset:
ISP Data Reset: All VoIP related configuration (mainly everything located on FXS
page).
VoIP Data Reset: All ISP (Internet Service Provider) configuration which may
affect the IP address.
Full Reset: Both VoIP and ISP related configuration at the same time.
Note: After choosing reset type, you will have to click the reset button for it to take
effect.
Key pattern to use PSTN line. Maximum 5 digits. Default is "*00"
PIN for VoIP-to-
PSTN Calls
Maximum 8 digits to authorize calling PSTN numbers from VoIP.
PIN for PSTN-to-
VoIP Calls
Maximum 8 digits to authorize calling VoIP terminals from PSTN.
