P a g e | 37

UCM630X Series User Manual

Version 1.0.2.25

Table 3: LCD Menu Options

View Events

 Critical Events

 Other Events

Device Info

 Hardware: Hardware version number

 Software: Software version number

 P/N: Part number

 WAN MAC: WAN side MAC address

 LAN MAC: LAN side MAC address

 Uptime: System uptime

Network Info

 WAN Mode: DHCP, Static IP, or PPPoE

 WAN IP: IP address

 WAN Subnet Mask

 LAN IP: IP address

 LAN Subnet Mask

Network Menu

 WAN Mode: Select WAN mode as DHCP, Static IP or PPPoE

 Static Route Reset: Select this to reset static route settings.

Factory Menu

 Reboot

 Factory Reset

 LCD Test Patterns

Press DOWN and OK buttons to scroll through and select different LCD

patterns to test. Once a test is done, press the OK button to return to the

previous menu.

 Fan Mode

Select Auto or On.

 LED Test Patterns

All On, All Off, and Blinking are the available options. Selecting Back in the

menu will revert the LED indicators back to their actual status.

 RTC Test Patterns

Select either 2022-02-22 22:22 or 2011-01-11 11:11 to start the RTC (Real-

Time Clock) test pattern. Check the system time from either the LCD idle

screen or in the web portal System StatusSystem InformationGeneral

page. To revert back to the correct time, manually reboot the device.
