Grandstream Networks UCM6304 - Figure 36: LDAP ServerLdap Phonebook; Figure 37: Add LDAP Phonebook

P a g e | 70
UCM630X Series User Manual
Version 1.0.2.25
add or delete contacts directly. The contacts information will need to be modified via Web
GUIExtension/TrunkExtensions first. The default LDAP phonebook will then be updated automatically.
Figure 36: LDAP ServerLDAP Phonebook
 Add new phonebook
A new sibling phonebook of the default PBX phonebook can be added by clicking on "Add" under "LDAP
Phonebook" section.
Figure 37: Add LDAP Phonebook
Configure the "Phonebook Prefix" first. The "Phonebook DN" will be automatically filled in. For example, if
configuring "Phonebook Prefix" as "people", the "Phonebook DN" will be filled with "ou=people,dc=pbx,dc=com".
Once added, users can select to edit the phonebook attributes and contact list (see figure below) or select
to delete the phonebook.
