Figure 10-2: 18kw and 24kw defl ectors
Figure 10-3: 32kw defl ectors
The condensate trap and the condensate outlet
must be checked at each service and cleaned if
necessary.
12. Replace the front cleaning door making sure the gasket is in
good condition and secure it in place with the nuts and washers
previously removed. Tighten to form a seal.
13. Remove the condensate trap and check that it is not clogged
and functioning properly, that is to say that the fl oat is free to move.
Clean the siphon and the fl oat if necessary. Refer to chapter 6.8.
14. Check that the condensate outlet of the boiler is not blocked.
Clean if necessary.
NOTE
Maintenance Of Your Boiler
Page 31
