CHAPTER 1 General Description
Configuration When in Use
Do not use the GL240 standing upright or at an angle. It must always be laid at or inclined on the stands.
<Usage Conguration>
Laid flat Inclined on the stands Opening the stands
90
˚
Do not block the air vent on the GL240, as this will cause malfunctioning.
Measurement accuracy may not be satisfactory if the system is used in a condition other than described
above.
To prevent possible toppling, use both of the stands of the GL240 when you place it inclined.
Use the GL240 with both of the two stands open as shown in the figure above.
