Grasshopper 721 User Manual

12
Yes
No
No
Yes
No
No
Yes
Steering levers
out, PTO switch
'OFF', parking
brake 'OFF',
operator 'OFF'
seat and engine
running.
Does engine die
when left
steering lever is
brought 'IN'?
Adjust or
replace left
steering switch.
Does engine die
when right
steering lever is
brought 'IN'?
Adjust or
replace right
steering switch.
Does engine die
when the PTO
switch turned
'ON'?
Replace PTO
switch.
Steering levers
out, PTO switch
'OFF', operator
'ON' seat,
parking brake
'ON' and engine
running. Does
engine die when
steering levers
are brought in?
Replace brake
switch.
No
Yes
Steering levers
in, PTO switch
'OFF', operator
'ON' seat,
parking brake
'OFF' and
engine running.
Does engine die
when operator
raises up off the
seat?
Replace seat
switch.
All safety
systems are
functioning
properly.
Yes
MODEL 720(Onan), 718D, 721D,
721 and 725
TESTING SAFETY SYSTEM FOR PROPER OPERATION
Notes:
Proper operation of the safety
system indicates that:
1. To start the engine, both steering
levers must be out, and the PTO
switch must be off. The engine
will start with the operator on or
off the seat and the parking
brake either on or off.
2. With the engine running and the
operator off the seat, the en-
gine will die if either steering
lever is brought in or the PTO
switch is turned on.
3. The engine will also die if the
operator gets off the seat with
either steering lever in or the
PTO switch turned on.
4. The engine will die if the steer-
ing levers are brought in with
the parking brake on.
