SYMBOLS USED ON WIRING DIAGRAMS
Indicates a ground point.
Indicates wires crossover but are not
connected.
Symbol indicating wires are connected.
Symbol for a diode. The arrow indicates
the direction of current flow. Current will
not flow in the other direction if the diode
is working properly.
Symbol for glass type fuse.
Symbol for automotive type fuse. The
number in the center of the fuse indicates
the amperage rating of the fuse.
Indicates wires are spliced.
0 0

Grasshopper 721 Specifications

General

Transmission	Hydrostatic
Drive	2WD
Cutting Width	61 in (155 cm)
Deck Material	Steel
Warranty	3 years
