Grasshopper EDGE-Eze User Manual

MANUAL LIFT EDGER ASSEMBLY
KIT NUMBER 533131
1 644598 Mount – Discharge w/Edger
2 824604 Pivot – Edger Height Adjust
(includes item 3)
3 833260 Bushing – Flanged 1"
4 824603 Pivot Arm – Edger Disc
(includes item 3)
5 604355 Fork w/O-Rings
425514 O-Ring
6 824149 Disc - Edger
7 783900 Hub - Edger
8 120048 Bearing – Ball .625
9 253189 Whiz Bolt .312-18 x .5
10 280776 Grease Fitting
11 247715 Carriage Bolt .625 x 5.625
12 253970 Lock Nut .625-11
13 422042 Shield – Flex Discharge
14 780650 Pin – Flex Discharge Shield
15 260608 Ring Cotter .054 x .375
16 732969 Spring Bracket
17 283848 Spring - Extension
18 821516 Washer – Nylon 1.5 x .531
19 243575 Bolt .5-13 x 1.75
20 243580 Bolt .5-13 x 2
21 253470 Nut – Nylon Insert .5-13
22 257061 Washer .5 x 2.25
23 821520 Washer – Nylon 2.0 x .781
24 885005 Spring Guide
25 283517 Spring - Compression
26 942177 Tube - Slider
27 243650 Bolt .5-13 x 7
28 643680 Lift Lever - Disc
29 833540 Grip – Handle Thumb Release
30 821675 Thumb Button – Push Rod
31 732593 Guide - Lever
32 253192 Whiz Bolt .312-18 x .75
33 253035 Whiz Nut .312-18
34 243330 Bolt .375-16 x 1
35 253890 Lock Nut .375-16
36 942350 Tube – Edger Linkage
37 902280 Spacer
38 243345 Bolt .375-16 x 1.75
39 774014 Washer .406 x 1.375 x 10 Ga.
40 257412 Lock Washer .375
41 243331 Bolt .375-24 x 1
42 252821 Stud .312-18 x 1 – 3 Prong Head
43 425514 O-Ring .801 ID x .070
44 723231 Fender – Disc
45 253177 Whiz Bolt .25-20 x .75 Truss
46 253025 Whiz Nut .25-20
47 755147 Plate - Disc Offset
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
01-06091A
Rev. 02-08
18
