Grasslin talento easy B1 - Overview; Design and Function

63
EN
Overview
Design and function
Fig. 1: Clock timer
1
Click system for installation on a DIN rail
2
Terminal for phase
3
Terminal for neutral conductor
4
Sealable housing
5
Display
6
Control buttons
7
Terminal for relay output
Description of function
The clock timer is a timer that is installed on a DIN rail (Fig.1/
1
) by means of a click system; the timer
controls the device that is connected via the output terminals (Fig. 1/
7
). The clock timer has one channel
and can be operated via a display (Fig.1/
5
) with four control buttons (Fig.1/
6
).
L
N
1
16(10)A 250V~
2
3
t
a
l
e
n
t
o
e
a
s
y
B1
1
2 3 4
5
6
7
