GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technnical modifications reserved. #0060384 04/2009
27
Schaltplan
3061
Fahrtregler
zum Empfänger
Motor
Motor
G2 Stecker G2 Stecker
Fahrtregler
zum Empfänger
G2 Stecker
G2 Stecker
Wasserpumpe
Schottelpumpjet
3061
Fahrakku
Fahrakku
3068
A
B
Fahrtregler
zum Empfänger
G2 Stecker
G2 Stecker
Wasserpumpe
Löschmonitor
A
3068
B
Akku Segelwinde
zum Empfänger
