GRAUPNER BERNHARD GRUBEN model boat - Comprehensive Parts List; Component Identification and Specifications

GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technnical modifications reserved. #0060384 04/2009
60
Parts List
No. Description No. off Material Size and thickness in mm
1 Boatstand, bow 2 Plywood 4 mm, laser-cut
2 Boatstand, stern 2 Plywood 4 mm, laser-cut
3 Boatstand, side 4 Plywood 4 mm, laser-cut
4 Hull 1 ABS Vac.-moulded, CNC-trimmed
5 Keel heel 2 ABS 1 mm, laser-cut
6 Schottel pump jet 2 ABS 1 mm, laser-cut
7 Stern tube 2 Metal Ready made
8 Motor mount 2 Plastic Ready made
9 Motor mount holder 1 Plywood 2 mm, laser-cut
10 Motor 2 Metal Order No. 3302
11 Shaft coupling 2 Aluminium Ready made
12 Shaft brace 4 ABS Ready made
13 R.H. propeller 1 Plastic Ready made
14 L.H. propeller 1 Plastic Ready made
15 Stern wall 1 ABS Vac.-moulded
16 Stern wall reinforcement 3 Plywood 4 mm, laser-cut
17 Rudder bush 2 Brass 4 / 3.1 Ø x 40 mm
18 Rudder shaft 2 Brass 3 Ø x 90 mm
19 Rudder blade (half-shells) 2 ABS Vac.-moulded
20 Rudder bush support 8 Plywood 2 mm, laser-cut
21 Rudder lever 2 Plastic Ready made
22 Swivel pushrod connector 4 Metal Ready made
23 Transverse rudder pushrod 1 Steel 1.5 Ø x 140 mm
24 Rudder servo support 5 Plywood 2 mm, laser-cut
25 Rudder servo 1 Various Order No. 4101.LOSE, or in RC set
26 Main rudder pushrod 1 Steel 1.5 Ø x 180 mm
27 Water pump 2 Various Order No. 1952
28 Schottel connecting nipple 2 Aluminium Tube, 4 / 3.1 Ø x 60 mm
29 Monitor intake nipple 1 Aluminium Tube, 4 / 3.1 Ø x 30 mm
30 Silicone hose, Schottel 2 Silicone Tube, 7 / 3 Ø x 170 mm
31 Silicone hose, monitor 2 Silicone Tube, 7 / 3 Ø x 500 mm + 150 mm
32 Anchor hawse 1 ABS Vac.-moulded
33 Hook servo support plate 1 Plywood 4 mm, from inner superstructure frame
34 Drive battery support plate 1 Plywood 4 mm, laser-cut
35 Forecastle deck 1 ABS Vac.-moulded, CNC-trimmed
36 Forec. deck reinforcement 3 Plywood 4 mm, laser-cut
37 Skylight 4 Plastic 1 mm, smoked-tint plastic
38 Main deck 1 ABS Vac.-moulded, CNC-trimmed
39 Main deck reinforcement 5 Plywood 4 mm, laser-cut
40 Stern cradle reinforcement 6 Spruce Rectangular strip, 5 x 8 mm, overlength
41 Lower rubbing strake 4 ABS Vac.-moulded
42 Sprayrail 2 ABS Vac.-moulded
43 Rubbing strake extension 2 ABS Vac.-moulded
44 Stern cradle 1 ABS Vac.-moulded
45 Reinforcing frame 5 Plywood 4 mm, laser-cut
46 Cable guide 2 Brass Tube, 3 / 2 Ø x 210 and 3 / 2 Ø x 25 mm
47 Inner roller bracket 8 ABS 1 mm, laser-cut
48 Roller axle 4 Brass Rod, 1.5 Ø x 13 mm
49 Roller 4 Plastic Ready made
50 Daughter boat lift 1 Brass Ready made
51 Sailwinch 1 Various Order No. 5173
52 Pull-cord 1 Polyester 0.8 Ø x 1500 mm
53 Small roller bracket 4 ABS 1 mm, laser-cut
54 Roller pivot 2 Nylon Tube, 1.9 / 0.9 Ø x 25 mm
55 Roller axle 2 Steel Rod, 0.8 Ø x 25 mm
