353 Cross-piece brace 2 1 ABS 1 mm, laser-cut
354 Centre mast extension 1 Brass Rod, 2 Ø x 46 mm
355 Centre mast ring 1 Brass Tube, 3 / 2 Ø x 5 mm
356 Transverse aerial 1 Brass Rod, 1.5 Ø x 30 mm
357 Vertical aerial 2 Brass Rod, 1.5 Ø x 24 mm
358 Crew-finder aerial 1 ABS Ready made
359 Aerial rod 4 Steel Wire, 0.8 Ø x 35 mm
360 Lamp mast 1 Brass Tube, 3 / 2 Ø x 125 mm
361 Centre lamp bracket 1 ABS 1 mm, laser-cut
362 Centre lamp brace 1 ABS 1 mm, laser-cut
364 Upper lamp bearer 1 ABS 1 mm, laser-cut
365 Upper lamp brace 1 ABS 1 mm, laser-cut
366 Aerial 1 ABS Ready made
367 Lamp mast brace 1 1 Brass Rod, 2 Ø x 32 mm
368 Lamp mast brace 2 1 Brass Rod, 2 Ø x 25 mm
369 Lamp mast brace 3 1 Brass Rod, 2 Ø x 78 mm
370 Centre mast outrigger 1 Brass Rod, 2 Ø x 50 mm
371 Centre mast aerial base 1 Brass Rod, 2 Ø x 22 mm
372 Centre mast aerial 1 Brass Rod, 1.5 Ø x 40 mm
373 Centre mast brace strut 2 Brass Rod, 1.5 Ø x 18 mm
374 Loop 1 ABS 1 mm, laser-cut
375 Bar mast outrigger 2 Brass Rod, 2 Ø x 55 mm
376 Bar mast aerial base 2 Brass Rod, 2 Ø x 22 mm
377 Bar mast VHF aerial 1 Brass Rod, 1.5 Ø x 55 mm
378 VHF aerial strut 3 Brass Wire, 0.5 Ø x 30 mm
379 Bar mast strut 2 Brass Rod, 1.5 Ø x 35 mm
380 Loop 2 ABS 1 mm, laser-cut
381 Lateral aerial mast 2 Brass Rod, 2 Ø x 105 mm
382 Aerial mast cross-piece 2 Brass Rod, 2 Ø x 33 mm
383 Aerial 4 Brass Wire, 0.5 Ø x 40 mm
384 Mast lamp 2 ABS Ready made
385 Panoramic lamp 7 ABS Ready made
386 Blue lamp 1 ABS Ready made
387 Bell 1 ABS Vac.-moulded
388 Radar aerial 2 ABS Ready made
389 Signal horn 1 ABS Ready made
390 Signal horn cover 1 ABS Vac.-moulded
391 Whip aerial
2 Steel Rod, 0.8 Ø x 250 mm
392 Aerial base
2 Nylon Tube, 1.9 Ø x 12 mm
393 Aerial holder 2 ABS Tube, 3.2 Ø x 10 mm
394 Rubber fender 8 Neoprene Flexible tube, 5 / 3 Ø, overlength
395 Centre axle 8 Brass Rod, 1.5 Ø, overlength
396 Lifesaver 4 ABS Vac.-moulded
397 Ball-fender 2 ABS Vac.-moulded
The Parts List also includes items which are not included in the kit, and have to be purchased separately.
As plan = as drawn on the plan; measure dimensions from the drawing.
Part No. with hyphenated numbers = these hyphenated numbers are intended to make it easier for the builder to allocate the
component parts of a sub-assembly.
