Receiver setup menu for helicopters
The receiver setup menu appears in the "Telemetry"
menu under SETTINGS / DISPLAYS or if you are using
a SMART-BOX under SETTING & DATAVIEW. How to
access this menu is described in the operating instruc-
tions supplied with your transmitter or Smart-Box.
Menu for GR-18Menu for GR-24
Display Explanation Settings
RECEIVER 1.0 1.0 indicates the version of the receiver's rmware -
Type of Model Selection of model type Plane, Heli
ALARM VOLT Alarm threshold for the receiver’s low voltage warn-
ing
2.5 – 24.0 V
Default setting: 3.0 V
ALARM TEMP Receiver overheating warning 50 – 80°C
Default setting: +70 °C
PERIOD Cycle time in ms 10 ms
LANGUAGE Select menu language English, French, German, Italian, Spanish
Model type selection (Type of Model): This is where you can choose the model type.
If you select "Plane", you can then set the gyro settings for xed-wing models on the menu screens, as described from
point 5.
If you select "Heli", you can then set the gyro settings of the integrated ybarless system for helicopters on the subse-
quent menu screens.
Low-voltage warning (ALARM VOLT): If the receiver voltage falls below the set value, a low-voltage warning is gen-
erated by the transmitter's RF module in the form of a "general alarm tone" (regular beeping at a rate of approx. one
beep per second) or the "receiver voltage" speech output message.
Temperature warning (ALARM TEMP): If the receiver temperature exceeds the set temperature, a warning is gen-
erated by the transmitter’s RF module in the form of a "general alarm tone" (regular beeping at a rate of approx. one
beep per second) or the "receiver temperature" speech output message.
Cycle time (PERIOD): If your system is used exclusively with digital servos, you can set a cycle time (frame rate) of
10 ms. If your system includes some or uses exclusively analogue servos, you should always select 20 ms, as many
analogue servos cannot process the higher frame rate and may respond by „jittering“ or „growling“.
WARNING: If you wish to use this option, you must observe the setup information supplied with the device
connected to the receiver, otherwise there is a risk that your model may be uncontrollable.
RECEIVER 1.0 <>
>Type of Model: HELI
ALARM VOLT: 3.0V
ALARM TEMP: 70°C
PERIOD: 10ms
LANGUAGE: english
RECEIVER 1.0 <>
>Type of Model: HELI
ALARM VOLT: 3.0V
ALARM TEMP: 70°C
PERIOD: 10ms
LANGUAGE: english
