Display overview
DEC
INC
ENTER
ESC
INC
DEC
SETTING AND DATAVIEW
RECEIVE+OLD SENSORS
> RECEIVE+GENERAL/GAS
RECEIVE+ELECTRONIC
RECEIVE+VARIO
RECEIVE+GPS
>SETTING AND DATAVIEW
MODEL SELECT
EXTERNAL MONITOR
SETTING AND DATAVIEW
>MODEL SELECT
EXTERNAL MONITOR
From HoTT Firmware version V4 on multiple sensors not only can be connected via a Y-cable and displayed
by the graphical mode MODEL SELECT, but also for example the alarm thresholds can be programmed in
the menu SETTING AND DATA VIEW. To do this, the sensor to be programmed must be selected in a fi rst
step.
Switch on the transmitter. On the startup screen appears SETTING AND DATA VIEW / MODEL SELECT /
EXTERNAL MONITOR. Move the arrow cursor with the INC or DEC buttons on SETTING AND DATAVIEW
and then press ENTER to go to the programming display.
SETTING AND DATAVIEW: up to fi rmware version V3 choose RECEIVE+OLD SENSOR - regardless of
which sensor is actually connected - from fi rmware V4 go to the menu line below and select the sensor to
be programmed:
RECEIVE+GENERAL/GAS = Receiver+GENERAL MODULE #33610 or #33611
RECEIVE+ELECTRONIC = Receiver+ELECTRIC AIR-MODUL #33620
RECEIVE+VARIO = Receiver+VARIO MODUL #33601
RECEIVE+GPS = Receiver+GPS #33600
The transmitter and receiver data is displayed in each menu.
The various programming options of the HoTT telemetry modules are described in detail in the instructions.
Note: when using fi rmware V3 and multiple sensors are connected via a Y-cable to the receiver, all sensores
that are not be programmed must be disconnected prior to the selection of the menu RECEIVE+OLD SEN-
SORS. Only one sensor may be connected! See also point 4 - telemetry display.
Unlike SETTING AND DATA VIEW, the telemetry data from MODEL SELECT or EXTERNAL MONITOR can
only be viewed but not be programmed. However, the data is represented in graphic form, and this makes it
the preferable option when actually operating a model, as it is easier and quicker to read and access.
MODEL SELECT: Graphical Display only for the transmitters mx-10 HoTT Order-No. 33110, mx-12 HoTT
Order-No. 4754, mx-16 HoTT Order No. 4755, mx-22 Order No. 4801/4802, mc-19 Order No. 4821 and mc-
22 Order No. 4818 after conversion to HoTT, as well as the modules M-G1 Order No. 33300, M-G2 Order
No. 33302 and Order No. 33301
EXTERNAL MONITOR: Graphical Display only for the transmitters mx-12 HoTT Order No. 33112, mx-16
HoTT Order No. 33116, mx-20 Order No. 33124 and mc-32 Order No. 33032 - operation by the transmitter.
See also point 4 - Telemetry display.
03 33700 SMART-BOX - Graupner HoTT 2.4
