3974_MP_V3
Technical data
16 channel digital switch module
Operating voltage 4,0 - 13,0 V
Operating current < 10mA at 6,0 V
Max. switch current pro chan-
nel
3.0 A
Max. switch voltage 18.0 V
Inpulse input voltage < 6,0 V
Weight approx. 16 g
Dimensions 57 x 42 x 15 mm
Operating temperature 0 - 40 °C
Required control channels 1 through SumD3
NOTE
The technical data of the optional receiver are available in the man-
ual included in the receiver package content.
Description
The Graupner transmitters mz-16, mz-32, mc-16 Expert and mc-32
Expert offer the possibility of controlling up to 16 different compo-
nents on the receiver side via the sum signal. The module works
exclusively via the digital switches of the above mentioned transmit-
ters.
The signals of the digital switches on the transmitter touch screen are
transmitted digitally, therefore the components are switched on and
off without delay and interference-free.
Through the suitable cabling of the connection cable the functions
can be powered by a single power source or separately by different
power sources.
(with a common ground, so not electrically isolated)
The compatible GR-12 / GR-16 / GR-24 / GR-32 receivers must be
up-to-date for SumD V3 software.
Go to:
www.graupner.de/UBlog/Empfaenger
