LED status display
Status Description Red LED Yellow LED Signal tone
Bind range
Bind status (small image) blinks (1s) lower tone (1)
Binding successful ON lower tone (2)
RX reception OK ON
Range test blinks quickly lower tone (2)/2 s
Error
Under voltage blinks quickly higher tone (4)/2 s
Sensor warning higher tone (3)/2 s
Rx voltage, temp. error blinks quickly higher tone (2)/2 s
Bad reception, no RX blinks slowly higher tone (1)/2 s
Factory Error lower tone (1)/2 s
Normal mode
Trim inc/dec lower tone (1)/click
Trim 0% higher tone (1)/click
Fail Safe mode start blinks 2x lower tone (2)
Fail safe (trim dn, hold) blinks 1x (5
times)
lower tone (1)
Fail safe (trim up, fail) blinks 2x (5
times)
higher tone (1)
Stick calibration
Calibration mode start blinks 3x
Stick calibration successful blinks 3x (3
times)
blinks 3x (3
times)
lower tone (2)
cut-off
"CUT-OFF" Motor on ON
"CUT-OFF" Motor off Off
Channel 2 reverse
Channel 2 Normal lower tone (1)
Channel 2 reverse lower tone (2)
Declaration of conformity
S1031 mz-4 HoTT
Graupner/SJ declares that the product is conform to EU norms.
EN 300 440-1 V1.6.1; EN 300 440-2 V1.4.1 3.2; EN 301 489-1
V1.9.2; EN 301 489-3 V1.6.1 3.1
EN 62479: 2010 3.1
EN 60950-1:2006 +A11:2009+ A1:2010+A12:2011+A2:2013
