Gravely 985103 - Page 9

3 -9
Model Number 985117
Description 13.5 HP Gear Drive
Brakes 7 x 1.75" Drum Type
Steering Manual, optional power
steering kit available
Turning Radius Zero (with steering kit)
Minimum Uncut Circle Zero
Optional Tire Sizes
-Stud Tread 4.00"-8"
-Trac Tread 4.00"-8"
-Turf-Chief 18" x 6.50"-8"
-Turf-Saver 18" x 8.50"-8"
-Semi-Pneumatic 16" x 5" x 3"
Tire Pressure See Tire Sidewall
Battery 12V BCI Group
Engine Robin
-Type EH410-0226T
-Horsepower 13.5 HP
-Number of Cylinders One
-Displacement 24.67 cu. in. (440 cc)
-Fuel Auto gasoline
-Fuel Capacity 1.5 gal. (5.7 L)
-Cooling Air
-Air Filter Dual element
-Lubrication Splash Type
-Oil Type See Engine Manual
-Oil Capacity 5 qts. (4.7 L)
-Oil Filter Spin on filter
-Charging System 12 volt, 12.5 amp
Transmission
-Type Gear transmission
-Oil Type SAE 30W API service
class SF or higher
-Oil Capacity 5 qts. (4.7 L)
-Cooling Air
-Number of Speeds 4 forward/4 reverse
-Direction Control
Speeds (with 18" tires)
-Forward 1st - 1.4 mph (2.3 kph)
2nd - 1.8 mph (2.9 kph)
3rd - 2.7 mph (4.4 kph)
4th - 3.7 mph (6.0 kph)
-Reverse 1st - 1.3 mph (2.1 kph)
2nd - 1.7 mph (2.7 kph)
3rd - 2.6 mph (4.2 kph)
4th - 3.3 mph (5.3 kph)
PTO
-Type Internal Slip Clutch
-Drive All gear shaft driven off
high/low planetary
-Output Speeds High - 1179 RPM,
Low - 888 RPM at 3300
engine RPM
Construction Cast-iron transmission
case with 7-gauge
framing
