GRE HPG25 - Page 29

26
No.
Part Name
No.
Part Name
1
Top cover
31
Rubber fixing block
2
Bracket panel
32
Gas return piping
3
Fan motor bracket
33
Compressor damping feet
4
Evaporator
34
Gas valve
5
Fan motor
35
Low pressure switch
6
Left Panel
36
Capillary
7
Fan blade
37
Transition pipe
8
Blue Strip
38
Gauga pipe
9
Front panel
39
Pipe(Exchanger to capillary)
10
Ventilation grill
40
Water outlet temp. sensor
11
Base tray
41
Exchanger temperature sensor clip
12
Evaporator temperature sensor
42
Red rubber ring
13
Sensor holder
43
Titanium heat exchanger
14
Clip
44
Water inlet temp. sensor
15
Evaporator pipe
45
Water connection sets
16
Side panel
46
Water connection sets
17
Cable connector
47
Blue rubber ring
18
Rubber plug
48
Sealing ring
19
Pressure gauge
49
Water flow switch
20
Controller
50
Electric box cover
21
Controller box
51
Capacitor clip
22
Controller cover
52
Compressor capacitance
23
Controller box cover
53
Transformer
24
Distribution pipe
54
Fan motor capacitance
25
Isolation panel
55
Electric box
26
Ambient temp. sensor
56
Two position terminal
27
Ambient temp. sensor clip
57
Clip
28
Discharge pipe
58
PCB
29
High pressure switch
59
Three position terminal
30
Compressor
