GRE HPG25 - Page 31

28
No.
Part Name
No.
Part Name
1
Top cover
33
Ambient temp. sensor clip
2
Bracket panel
34
Compressor
3
Fan motor bracket
35
Low pressure switch
4
Evaporator
36
Gas valve
5
Isolation panel
37
Rubber fixing block
6
Fan motor
38
Gas return piping
7
Fan blade
39
Compressor damping feet
8
Left Panel
40
Discharge pipe
9
Blue Strip
41
Capillary
10
Front panel
42
Transition pipe
11
Ventilation grill
43
Pipe
12
Base tray
44
High pressure switch
13
Evaporator temperature sensor
45
Pipe(Exchanger to capillary)
14
Clip
46
Water outlet temp. sensor
15
Sensor holder
47
Sensor clip
16
Evaporator pipe
48
O'ring
17
Distribution pipe
49
Water connection sets
18
Side panel
50
Water connection sets
19
Cable connector
51
Blue rubber ring
20
Rubber plug
52
Water inlet temp. sensor
21
Pressure gauge
53
Clip
22
Controller cover
54
Titanium heat exchanger
23
Controller
55
Red rubber ring
24
Controller box
56
Water flow switch
25
Controller box cover
57
Electric box cover
26
Support plate
58
Compressor capacitance
27
Wiring box
59
Transformer
28
Two position terminal
60
Scale panel
29
Clip
61
Electric box
30
Three position terminal
62
PCB
31
Back panel
63
Fan motor capacitance
32
Ambient temp. sensor
64
Capacitor clip
