GRE HPG25 - Page 33

30
No.
Part Name
No.
Part Name
1
Top cover
33
Ambient temperature sensor
2
Support plate
34
Sensor clip
3
Motor bracket
35
Exhaust pipe
4
Evaporator
36
High pressure switch
5
Left Panel
37
Low pressure switch
6
Fan motor
38
Fixing block
7
Fan blade
39
Needle valve
8
Front ventilation panel
40
Capillary
9
Ventilation grill
41
Transition pipe
10
Isolation Panel
42
Gas return pipe
11
Compressor
43
Pressure pipe
12
Rubber feet of compressor
44
Titanium exchanger to capillary
13
Cable connector
45
Sensor Clip
14
Controller box
46
Water inlet temperature sensor
15
Cable connector
47
Titanium heat exchanger
16
Rubber ring
48
Blue Rubber ring
17
Pressure gauge
49
O'ring
18
Side panel
50
Water connection
19
Controller
51
Red Rubber ring
20
Waterproof box
52
Sealing ring for flow switch
21
Support plate
53
Water flow switch
22
Wiring box
54
Water outlet temperature sensor
23
Two position terminal
55
Electric box cover
24
Three position terminal
56
Capacitor clamp
25
Clamp
57
Compressor capacitance
26
Distributor pipe
58
PCB
27
Back panel
59
Fan capacitance
28
Rubber fixing block
60
Scale panel
29
Collecting Pipe
61
Transformer
30
Sensor casing pipe
62
AC contactor
31
Spring blade of sensor pipe
63
Electric box
32
Coil pipe Temp sensor
