D Series Modular Air-cooled Scroll Chillers
Service Manual
Fan
1RWH%HVXUHWRFXWRIIWKHSRZHUVXSSO\¿UVWO\
Steps Graphic Representation nstructions
1. Remove
the panel as
shown in the
ULJKW¿JXUH
ƹ
Remove the panel as shown in the left
¿JXUH
2. Remove
the guard
cover
ƹ
Remove the guard cover with a wrench.
3. Remove
the fan
blades
ƹ
Remove the fan blades with a screwdriver.
