Gree D Series Service Manual

5
D Series Modular Air-cooled Scroll Chillers
Service Manual
QSPEVDU
1RPLQDOFDSDFLWLHVDUHEDVHGRQWKHIROORZFRQGLWLRQV
Item
Water side Air side
:DWHUÀRZYROXPH Leaving Water Temperature Dry-bull temp. Wet-bull temp.
m
3
/(h·kw) (
ć
/

)(
ć
/

)(
ć
/

)
Cooling
0.172
7/45 35/95 —
Heating 45/113 7/45 6/43
4.3 Operation Range
Water side Air side
Leaving Water Temperature Temperature Difference of Water Air on Condenser
(
ć
/

)(
ć
/

)(
ć
/

)
Cooling 5~15/41~59 2.5~6/37~43 15~45/59~113
Heating 40~50/104~122 2.5~6/37~43 -15~24/5~75
Note: when the unit is going to operate beyond the working conditions, please contact Gree for consultation.
4.4 Electric Data
Model Rated Power Supply
Compressor Fan Motor Air Switch
Qty
MRC Each
(A)
NRC Each
(A)
Qty.
NRC Each
(A)
MRC
(A)
LSQWRF65M/NaD-M
380-415V
,
3Ph,50Hz
2 29.1 17.6 2 1.71 63
LSQWRF80M/NaD-M 2 29.3 25.7 2 2.50 80
LSQWRF130M/NaD-M 4 29.1 17.6 4 1.71 125
LSQWRF160M/NaD-M 4 35 25.7 4 2.50 160
Notes:
05&0D[LPXPUXQQLQJFXUUHQW$
NRC: Nominal running current (A).
