D Series Modular Air-cooled Scroll Chillers
9
(5) Graph for the shape and dimensions for LSQWRF160M/D-M
(Unit:mm)
403
2160
1676
2226
1650
2026(Ground bolt 4-M12)
1617(Ground bolt 4-M12)
317
(6) Graph for the shape and dimensions for LSQWRF160M/NaD-M
(Unit:mm)
403
337
1676
2226
2026(Ground bolt 4-M12)
1617(Ground bolt 4-M12)
1650
2160
