Super Free Match
Service Manual
MAINTENANCE
182
◆ Cozy
GWH(07)MA-K3DNA3E/I; GWH(09)MA-K3DNA3E/I; GWH(12)MB-K3DNA3E/I
Part list:
GWH(07)MA-K3DNA3E/I for CB171N08600; GWH(09)MA-K3DNA3E/I for CB171N08501;
GWH(12)MB-K3DNA3E/I for CB171N08701
GWH(07)MA-K3DNA3E/I
GWH(09)MA-K3DNA3E/I
GWH(12)MB-K3DNA3E/I
NO. Description
Code Qty Code Qty
1 Receiver Window 20192229 1 22432230 1
2 Front Panel Assy 20012241 1 20012548 1
3 Filter Sub-Assy 11122081 2 1112220403 2
4 Screw Cover 24252016 3 24252016 1
5 Front Case 20012120C 1 2001213908 1
6 Air Louver 2 10512114 1 10512155 1
7 Air Louver 1 10512113 1 10512156 1
8 Helicoid tongue 26112162 1 26112163 1
9 (Left) Axile Bush 10542704 1 10542037 1
To Next Page
