Gree GMV-335WM/G-X Service Manual

Gree GMV6 DC Inverter VRF Units Service Manual
9
Model - GMV-2295WM/G-X GMV-2350WM/G-X GMV-2414WM/G-X GMV-2470WM/G-X
HP HP 82 84 86 88
Combination mode
- 20+20+20+22 20+20+22+22 18+22+22+24 20+22+22+24
-
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 229.5 235.0 241.4 247.0
Heating capacity kW 258.0 264.0 271.0 277.5
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 69 69 69 70
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 13.8+13.8+13.8+16.2
13.8+13.8+16.2+16.
2
12.3+16.2+16.2+
20.5
13.8+16.2+16.2+20.
5
Heating power input kW 13.1+13.1+13.1+16.9
13.1+13.1+16.9+16.
9
12.9+16.9+16.9+20.
1
13.1+16.9+16.9+20.
1
Cooling current input A
24.7+24.7+24.7+
29.0
24.7+24.7+29.0+
29.0
22.0+29.0+29.0+
36.6
24.7+29.0+29.0+
36.6
Heating current
input
A
23.4+23.4+23.4+
30.2
23.4+23.4+30.2+
30.2
23.1+30.2+30.2+
35.9
23.4+30.2+30.2+
35.9
Rated power input kW
26.85+26.85+26.85+2
7.41
26.85+26.85+27.41+
27.41
26.30+27.41+27.41+
27.41
26.85+27.41+27.41+
27.41
Rated current A
48+48+48+
49
48+48+49+
49
47+49+49+
49
48+49+49+
49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8+8+8+8.3 8+8+8.3+8.3 8+8.3+8.3+8.3 8+8.3+8.3+8.3
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe mm Φ44.5 Φ44.5 Φ44.5 Φ44.5
Liquid pipe mm Φ22.2 Φ22.2 Φ22.2 Φ22.2
Outline dimensions
(W x D x H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W x D x H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 350+350+350+350 350+350+350+350 295+350+350+355 350+350+350+355
Gross weight kg 365+365+365+365 365+365+365+365 310+365+365+370 365+365+365+370
Model - GMV-2525WM/G-X GMV-2590WM/G-X GMV-2655WM/G-X GMV-2720WM/G-X
HP HP 90 92 94 96
Combination mode
- 22+22+22+24 22+22+24+24 22+24+24+24 24+24+24+24
-
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 252.5 259.0 265.5 272.0
Heating capacity kW 283.5 291.0 298.5 306.0
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 70 70 70 70
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW
16.2+16.2+16.2+
20.5
16.2+16.2+20.5+
20.5
16.2+20.5+20.5+
20.5
20.5+20.5+20.5+
20.5
Heating power input kW
16.9+16.9+16.9+
20.1
16.9+16.9+20.1+
20.1
16.9+20.1+20.1+
20.1
20.1+20.1+20.1+
20.1
