Gree GMV-335WM/G-X Service Manual

Gree GMV6 DC Inverter VRF Units Service Manual
8
Model - GMV-1845WM/G-X GMV-1910WM/G-X GMV-1975WM/G-X GMV-2040WM/G-X
Rated current A 49+49+49 49+49+49 49+49+49 49+49+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8.3+8.3+8.3 8.3+8.3+8.3 8.3+8.3+8.3 8.3+8.3+8.3
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe mm Φ41.3 Φ44.5 Φ44.5 Φ44.5
Liquid pipe mm Φ19.05 Φ22.2 Φ22.2 Φ22.2
Outline dimensions
(W x D x H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W x D x H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 350+350+350 350+350+355 350+355+355 355+355+355
Gross weight kg 365+365+365 365+365+370 365+370+370 370+370+370
Model - GMV-2069WM/G-X GMV-2129WM/G-X GMV-2190WM/G-X GMV-2245WM/G-X
HP
HP
74
76
78
80
Combination mode
- 12+18+22+22 16+18+20+22 14+20+22+22 14+22+22+22
-
GMV-335WM/G-X+
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-450WM/G-X+
GMV-504WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-400WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-400WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 206.9 212.9 219.0 224.5
Heating capacity kW 232.0 238.5 246.0 252.0
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 68 68 69 69
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 7.7+12.3+16.2+16.2 10.8+12.3+13.8+16.2 9.2+13.8+16.2+16.2 9.2+16.2+16.2+16.2
Heating power input kW 7.8+12.9+16.9+16.9 10.7+12.9+13.1+16.9 9.5+13.1+16.9+16.9 9.5+16.9+16.9+16.9
Cooling current input A 13.8+22.0+29.0+29.0 19.3+22.0+24.7+29.0 16.4+24.7+29.0+29.0 16.4+29.0+29.0+29.0
Heating current input A 13.9+23.1+30.2+30.2 19.1+23.1+23.4+30.2 17.0+23.4+30.2+30.2 17.0+30.2+30.2+30.2
Rated power input kW
13.50+26.30+
27.41+27.41
18.74+26.30+
26.85+27.41
18.18+26.85+
27.41+27.41
18.18+27.41+
27.41+27.41
Rated current A 24.1+47+49+49 30.2+47+48+49 32.5+48+49+49 32.5+49+49+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 5.7+8+8.3+8.3 7.5+8+8+8.3 7+8+8.3+8.3 7+8.3+8.3+8.3
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe mm Φ44.5 Φ44.5 Φ44.5 Φ44.5
Liquid pipe mm Φ22.2 Φ22.2 Φ22.2 Φ22.2
Outline dimensions
(W x D x H)
mm
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W x D x H)
mm
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 220+295+350+350 290+295+350+350 290+350+350+350 290+350+350+350
Gross weight kg 230+310+365+365 305+310+365+365 305+365+365+365 305+365+365+365

Gree GMV-335WM/G-X Specifications

General

Brand	Gree
Model	GMV-335WM/G-X
Category	Inverter
Language	English
