Gree GMV-335WM/G-X Service Manual

Gree GMV6 DC Inverter VRF Units Service Manual
7
Model - GMV-1399WM/G-X GMV-1455WM/G-X GMV-1510WM/G-X GMV-1565WM/G-X
Gross weight kg 230+310+365 225+365+365 225+365+365 230+365+365
Model - GMV-1623WM/G-X GMV-1679WM/G-X GMV-1734WM/G-X GMV-1790WM/G-X
HP
HP
58
60
62
64
Combination mode
- 18+18+22 18+20+22 18+22+22 20+22+22
-
GMV-504WM/G-X+
GMV-504WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 162.3 167.9 173.4 179.0
Heating capacity kW 182.0 188.5 194.5 201.0
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 67 67 67 68
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 12.3+12.3+16.2 12.3+13.8+16.2 12.3+16.2+16.2 13.8+16.2+16.2
Heating power input kW 12.9+12.9+16.9 12.9+13.1+16.9 12.9+16.9+16.9 13.1+16.9+16.9
Cooling current input A 22.0+22.0+29.0 22.0+24.7+29.0 22.0+29.0+29.0 24.7+29.0+29.0
Heating current
input
A 23.1+23.1+30.2 23.1+23.4+30.2 23.1+30.2+30.2 23.4+30.2+30.2
Rated power input kW 26.30+26.30+27.41 26.30+26.85+27.41 26.30+27.41+27.41 26.85+27.41+27.41
Rated current A 47+47+49 47+48+49 47+49+49 48+49+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8+8+8.3 8+8+8.3 8+8.3+8.3 8+8.3+8.3
Maximum drive IDU
NO.
unit 77 80 80 80
Gas pipe mm Φ41.3 Φ41.3 Φ41.3 Φ41.3
Liquid pipe mm Φ19.05 Φ19.05 Φ19.05 Φ19.05
Outline dimensions
(W x D x H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W x D x H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 295+295+350 295+350+350 295+350+350 350+350+350
Gross weight kg 310+310+365 310+365+365 310+365+365 365+365+365
Model - GMV-1845WM/G-X GMV-1910WM/G-X GMV-1975WM/G-X GMV-2040WM/G-X
HP HP 66 68 70 72
Combination mode
- 22+22+22 22+22+24 22+24+24 24+24+24
-
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 184.5 191.0 197.5 204.0
Heating capacity kW 207.0 214.5 222.0 229.5
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 68 69 69 69
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 16.2+16.2+16.2 16.2+16.2+20.5 16.2+20.5+20.5 20.5+20.5+20.5
Heating power input kW 16.9+16.9+16.9 16.9+16.9+20.1 16.9+20.1+20.1 20.1+20.1+20.1
Cooling current input A 29.0+29.0+29.0 29.0+29.0+36.6 29.0+36.6+36.6 36.6+36.6+36.6
Heating current input A 30.2+30.2+30.2 30.2+30.2+35.9 30.2+35.9+35.9 35.9+35.9+35.9
Rated power input kW 27.41+27.41+27.41 27.41+27.41+27.41 27.41+27.41+27.41 27.41+27.41+27.41
