Multi Variable Air Conditioners Wall Mounted Type Indoor Unit
11
(3) Connect the power cord of external water pump to the positions L and N of terminal CN8 of
the main board; connect the alarm wire to the positions 1 and 2 of terminal CN35 (refer to
Fig. 5.7).
(4) Ake out the wiring clip from the package of accessories. Remove the original wiring clip from
the electric box and secure the power cord and alerter wire with the new clip.
Fig. 5.7
