Gree GMV-ND06G/B4B-T - 2 Product Introduction; Outline of the Unit and Main Parts; Rated Operating Condition

Multi Variable Air Conditioners Wall Mounted Type Indoor Unit
2
Any personal injury or property loss caused by improper installation, improper debug, and
unnecessary repair or not following the instructions of this manual should not be the responsibility of
Gree Electric Appliances, Inc. of Zhuhai.
2 Product Introduction
2.1 Outline of the Unit and Main Parts
Fig. 2.1
NOTE
The appearances will be different by the different models of air conditioners.
No.
Part Name
No.
Part Name
①
Surface panel
④
Guide louver
②
Filter
⑤
Drain pipe
③
Wiring cover
— —
2.2 Rated Operating Condition
Item
Indoor Side Condition
Outdoor Side Condition
Dry Bulb Temp°C (°F)
Wet Bulb Temp°C (°F)
Dry Bulb Temp°C (°F)
Wet Bulb Temp°C (°F)
Rated Cooling
27(80.6)
19(66.2)
35(95)
24(75.2)
Rated Heating
20(68.0)
15(59.0)
7(44.6)
6(42.8)
Indoor Unit Working Temperature Range: 16°C(60.8
°F)
~32°C(89.6
°F)
.
(26) Volatile liquid, such as diluent or gasoline, will damage the appearance of air conditioner. Only soft dry cloth and
wet cloth dipped with neutral detergent can be used to clean the outer case of air conditioner.
(27) If there are any abnormal circumstances (such as burning smell, etc.), please turn off the unit and cut off the main
power supply immediately, and then contact Gree appointed service center. If those abnormal circumstances still
exit, the unit may be damaged and it may lead to electric shock or fire hazard.
(28) Under the standby status, the air conditioner will consume a little power for ensuring reliability of complete air
conditioner, maintaining normal communication and preheating refrigerant. When the unit won’t be used for a
long time, cut off the power of the complete air conditioner. However, please preheat it when operating the unit
next time.
