Gree GMV-ND06G/B4B-T - Electric Installation

Multi Variable Air Conditioners Wall Mounted Type Indoor Unit
4
Material type
To
tal length of communication
line between indoor unit and
wired controller L
Wire size Remarks
Light/Ordinary
polyvinyl chloride
sheathed cord.
L≤250m
(L≤820-1/5feet)
2×AW G18
~2×AWG16
(1) Total length of communication line can't exceed
250m (820-1/5feet).
(2) The cord shall be Circular cord (the cores shall be
twisted together).
(3) If unit is installed in places with intense magnetic
field or strong interference, it is necessary to use
shielded wire.
3.2.2 Select Communication Line for Indoor Unit and Indoor Unit (Outdoor Unit)
Fig. 3.2.2
Material Type
Total Length L of
Communication Cable
between Indoor Unit and
Indoor (Outdoor) Unit
Wire size Remarks
Light/Ordinary
polyvinyl chloride
sheathed cord.
L≤1000m
(L≤3280-5/6feet)
≥2×AWG18
(1) If the wire diameter is enlarged to 2×AWG16, the
total communication line length can reach 1500 m
(4921-1/4feet).
(2) The cord shall be Circular cord (the cores shall be
twisted together).
(3) If unit is installed in places with intense magnetic
field or strong interference, it is necessary to use
shielded wire.
3.3 Electric Installation
Model
Power Supply
MCA(A)
MOP(A)
GMV-ND06G/B4B-T(U)
GMV-ND07G/B4B-T(U)
GMV-ND09G/B4B-T(U)
GMV-ND12G/B4B-T(U)
GMV-ND14G/B4B-T(U)
GMV-ND18G/B4B-T(U)
GMV-ND24G/B4B-T(U)
GMV-ND30G/B4B-T(U)
GMV-ND36G/B4B-T(U)
208/230V-1ph-60Hz 1 15
