Gree GMV-ND22PLS/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
209
Above data is subject to change without notice,pls reference the SP in global service website.
5
Front Case Sub-assy
'2001213931
1
6
Evaporator Assy
01024100097
.2
7
Strainer
'07414100006
...4
8
Strainer
'07213050
...4
9
Electronic Expansion Valve
'07334463
...4
10
Electric Expand Valve Fitting
'4304413217
.2
11
Axile Bush
'10542036
1
12
Rear Grill
'01472013
1
13
Motor Press Plate
'26904100117
1
14
Fan Motor
'1501208905
1
15
Electric Box Cover2
'2012207504
1
16
Shield Cover of Electric Box
Sub-assy
'01592073
1
17
Electric Box Cover1
'2224213502
1
18
Display Board
'30565007
.2
19
Remote Controller
'30510589
1
20
Lower Shield Sub-assy of
Electric Box
'01592072
.2
21
Electric Box Assy
'01394100451
1
22
Main Board
'30226000061
.2
23
Terminal Board
'42010268
.2
24
Electric Box
'2011216702
.2
25
Connecting pipe clamp
'26112164
1
26
Stepping Motor
'1521212901
.2
27
Crank
'10582070
.2
28
Wall Mounting Frame
'01252021
1
29
Rear Case Sub-Assy
'2220294712
.2
30
Air Louver 1
'10512164
.2
31
Air Louver 2
'10512165
.2
32
Left Axile Bush
'10512037
.2
33
Temperature Sensor
'390000454
1
34
Temperature Sensor
'39000076G
1
35
Temperature Sensor
'390002072G
1
36
Cross Flow Fan
'10454101
1
37
O-Gasket of Cross Fan
Bearing
'76512203
..3
