MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
154
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND56PHS/A-T
CM800N3690
GMV-ND63PHS/A-T
CM800N3700
GMV-ND71PHS/A-T
CM800N3540
GMV-ND80PHS/A-T
CM800N3710
Part code
Quantity
1
Filter Sub-Assy
'11125303
2
2
Guide groove of the filter
screen
'02285301
1
3
Evaporator Assy
'01024100090
1
4
Electric Expand Valve Fitting
'4304413215
1
5
Electronic Expansion Valve
'07334466
1
6
Strainer
'0741410000601
1
7
Filter
'07415210
1
8
Lower Cover Plate Sub-Assy
'01265304
1
9
Water Tray Assy
'01285317
1
10
Choke Plug of Drain Pipe
'76712455
2
11
Water Pump
'4313822001
1
12
Water Level Switch
'450127011
1
13
Right Side Plate
'01314100063
1
14
Seal plate'
'01494100008
1
15
Cover Plate
'01264100036
1
16
Electric Box Assy
'01394100255
1
17
Main Board
'30226000027
1
18
Terminal Board
'42011154
1
19
Terminal Board
'4201800002601
1
20
Inductance
'43128000014
1
21
Electric Box Cover
'01424100078
1
22
Centrifugal fan assy
'15405200029
1
23
Blower Mounting Plate Sub-
Assy
'01325200039
1
24
Supporter
'01804100140
1
25
Blower
'15012454
1
26
Brushless DC Motor
'15705200006
1
27
Blower
'15012458
1
28
Top Cover Board Assy
'01265226
1
29
Hook
'02112446
4
30
Left Side Plate Assy
'01314155
1
31
Sensor Sub-assy
'39004169G
1
32
Display Board
'30296000040
1
Above data is subject to change without notice,pls reference the SP in global service website.
