MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
166
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-
ND56PLS/A-T
CM800N3510
GMV-
ND63PLS/A-T
CM800N3430
Part code
Quantity
Part code
Quantity
17
Terminal Board
'4201800002601
1
'4201800002601
1
18
Electric Box Cover
'01424100035
1
'01424100035
1
19
Sealplate sub-assy (drainage)
'01495315
1
'01495315
1
20
Sealplate sub-assy (outlet)
'01495316
1
'01495316
1
21
Left Side Plate Assy
'01315200087
1
'01315200087
1
22
Water Level Switch
'45020216
1
'45018012
1
23
Water Pump
'43130324
1
'43130324
1
24
Filter Sub-Assy
'07210028
1
'07210028
1
25
Strainer
'0741410000601
2
'0741410000601
2
26
Electronic Expansion Valve
'07334466
1
'07334494
1
27
Evaporator Assy
'01024100111
1
'01024100029
1
28
Cover of Air Outlet
'01265335
1
'01265335
1
29
Air Outlet Frame Assy
'01374635
1
'01374635
1
30
Water Tray Assy
'01285334
1
'01285334
1
31
Supporter
'01895225
2
'01895225
2
32
Top Cover Board Assy
'01265339
1
'01265339
1
33
Choke Plug of Drain Pipe
'76815214
2
'76815214
2
34
Right Side Plate Assy
'01305263
1
'01305263
1
35
Display Board
` 30296000040
1
` 30296107
1
36
Sensor Sub-assy
'39004168G
1
'39004168G
1
37
Drain Hose Sub-Assy
'05232050
1
'05232050
1
Above data is subject to change without notice,pls reference the SP in global service website.
