Gree GMV-Pdm224W/NaB-M User Manual

DC Inverter Multi
VRF Service Manual
7
PRODUCT
Model(Combined unit) — — GMV-Pdm504W2/NaB-M
Model GMV-Pdm400W/NaB-M GMV-Pdm450W/NaB-M
GMV-Pdm224W/NaB-M
+GMV-Pdm280W/NaB-M
Capacity
Cooling
kW 40 45 50.4
kBtu/h 136.48 153.54 171.964
Heating
kW 45 50 56.5
kBtu/h 153.54 170.6 192.778
Sound Pressure Level dB(A) 61 61 62
Power Supply V/Hz/Ph 380-415V~50Hz-3Ph
Power input
Cooling kW 12.45 14.32 5.52+7.52
Heating kW 11.2 13.9 5.82+7.70
Current
Cooling A 22.25 25.6 9.87+13.44
Heating A 20.02 24.85 10.4+13.76
Circuit breaker A 40 40 32+32
Recommended
Power Lines
mm
2
×N 10×5 10×5 6×5+6×5
Moisture protection IP24 IP24 IP24
Climate Type T1 T1 T1
Connecting
pipe
Gas Pipe
mm Φ28.6 Φ28.6 Φ28.6
Inch 9/8 9/8 9/8
Liquid
Pipe
mm Φ12.7 Φ12.7 Φ15.9
Inch 1/2 1/2 5/8
Oil Pipe
mm — — Φ12.7
Inch — — 1/2
Connection Method Brazing Connection Brazing Connection Brazing Connection
Dimensions
of Unit
Width mm 1340 1340 930+930
Depth mm 770 770 770+770
Height mm 1670 1670 1670+1670
Dimensions
of Package
Width mm
1420 1420 1010+1010
Depth mm 850 850 850+850
Height mm 1850 1850 1850+1850
Net Weight kg 350 370 255+255
Gross Weight kg 380 400 275+275
Loading Quantity
( 20’ Container )
unit 7 7 ——
Loading Quantity
( 40’ Container )
unit 16 16 ——
Loading Quantity ( 40’
High Cube Container )
unit 24 24 ——
Notes:
① .
The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
② .
The data will change with the change of products. Refer to those parameters listed on nameplate.
③ .
The charge amount of refrigerant in the list is the datum when there is not drop height vertically between
indoor unit and outdoor unit, without consideration of connection pipe. So calculate the additional charge amount
according to actual condition during installation.
④ .
Section area of lead wire is only applicable for 15-m distance.If above, increase the section area to avoid
overload of current which would cause burnout of lead wire.
⑤ .
The outdoor fan of this unit is without static pressure.If static pressure is required, please specially notice it on
purchase order.
⑥ .
Running condition of cooling: outdoor temperature -5 ~48 ; Running condition of heating: outdoor
temperature -20 ~27 .
