GMV5 Compact Series VRF Outdoor Unit
4
3 Before Installation
Remarks: the pictures are for reference only, and the all the unit is in “mm”.
3.1 Standard Accessories
Please use the below standard accessories as per the instruction
Accessories for outdoor unit
S/N
Name
Appearance
Qty
Remarks
1
User Manual
1
2
Flexible Pipe
1
3
Resistance
1
This resistance should be connected
to the last indoor unit
3.2 Installation Location
3.2.1 Choose the Location for Installation of Indoor Unit
（1） Keep the indoor unit away from sunshine.
（2） The ceiling and suspender should be strong enough to support the indoor unit.
（3） Please choose the location.
（4） Please keep the air outlet and air inlet away from the barriers.
（5） The location for installation should be easy for piping.
（6） Please keep the indoor units away from incendive materials and explosive materials.
（7） Please keep the indoor units away from the location with high humidity and high corrosive
3.2.2 Choose the Location for Installation of Outdoor Unit
（1） The outdoor units should be installed on the solidity foundation
（2） The outdoor units should be installed near to indoor units as much as possible and the length of piping
The installation should follow the local safety regulation.
Please contact with our local agent or dealers to install the unit.
Don’t turn on the power until finishing the installation.
