101
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
GMV-Q96WM/B-U(U)
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
130%
-3.5 -4.0 70.0 5.55 69.6 5.94 69.3 6.33 69.3 6.53 68.9 6.72 68.9 7.12
-2.0 -2.5 71.0 5.67 70.6 6.06 70.6 6.45 70.3 6.64 70.3 6.82 70.0 7.21
2.0 1.5 73.7 5.94 73.4 6.30 73.0 6.68 73.0 6.83 73.0 7.05 72.7 7.43
7.0 5.0 76.8 6.21 76.5 6.57 76.1 6.93 76.1 7.10 75.8 7.28 75.8 7.64
11.0 8.5 79.9 6.49 79.9 6.83 79.6 7.17 79.2 7.34 79.2 7.52 78.9 7.85
14.5 12.0 83.7 6.77 83.3 7.10 83.0 7.43 83.0 7.59 83.0 7.75 82.6 8.08
15.0 14.0 85.7 6.92 85.4 7.23 85.0 7.55 85.0 7.71 84.7 7.86 84.7 8.18
17.0 16.0 87.4 7.04 87.1 7.34 87.1 7.66 86.8 7.81 86.8 7.97 86.4 8.28
19.5 18.0 90.5 7.24 90.5 7.55 90.2 7.84 90.2 8.00 89.8 8.14 89.5 8.45
23.0 22.0 95.3 7.52 95.0 7.65 94.6 8.09 94.6 8.23 94.3 8.36 94.3 8.65
26.5 25.0 99.8 7.76 99.4 8.04 99.4 8.30 99.1 8.45 99.1 8.58 98.8 8.84
32.0 30.5 107.7 8.14 107.7 8.39 107.3 8.64 107.3 8.76 107.0 8.89 107.0 9.14
37.5 36.0 116.2 8.48 115.9 8.71 115.6 8.95 115.6 9.06 115.6 9.18 115.2 9.40
41.0 40.0 122.1 8.69 121.7 8.91 121.7 9.13 121.4 9.24 121.4 9.35 121.0 9.57
45.0 43.0 128.2 8.89 127.9 9.10 127.9 9.31 127.6 8.39 127.6 9.52 122.4 9.14
48.0 46.0 134.8 9.08 134.4 9.28 134.4 9.48 134.1 9.58 131.3 9.38 122.4 8.59
52.0 50.0 141.6 9.26 141.3 9.45 140.6 9.57 135.8 9.19 131.3 8.81 122.4 8.09
55.0 53.0 149.2 9.44 148.8 9.62 140.6 8.97 135.8 8.61 131.3 8.27 122.4 7.59
59.0 57.0 156.4 9.60 149.5 9.11 140.6 8.45 135.8 8.12 131.3 7.79 122.4 7.16
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
120%
-3.5 -4.0 69.6 6.08 69.3 6.44 68.9 6.80 68.9 6.98 68.9 7.16 68.6 7.53
-2.0 -2.5 70.6 6.19 70.3 6.55 70.3 6.83 70.0 7.08 70.0 7.26 69.6 7.62
2.0 1.5 73.4 6.44 73.0 6.78 73.0 7.12 72.7 7.29 72.7 7.47 72.4 7.80
7.0 5.0 76.5 6.69 76.1 7.02 75.8 7.34 75.8 7.52 75.8 7.68 75.4 8.01
11.0 8.5 79.6 6.95 79.6 7.26 79.2 7.58 79.2 7.74 78.9 7.89 78.9 8.21
14.5 12.0 83.3 7.21 83.0 7.51 83.0 7.81 82.6 7.97 82.6 8.11 82.3 8.43
15.0 14.0 85.4 7.34 85.0 7.64 84.7 7.93 84.7 8.08 84.7 8.16 84.4 8.52
17.0 16.0 87.1 7.46 86.8 7.74 86.8 8.03 86.4 8.17 86.4 8.32 86.1 8.61
19.5 18.0 90.2 7.65 90.2 7.93 89.8 8.20 89.8 8.34 89.5 8.48 89.5 8.75
23.0 22.0 95.0 7.89 94.6 8.16 94.3 8.43 94.3 8.56 94.3 8.69 94.0 8.95
26.5 25.0 99.4 8.13 99.4 8.38 99.1 8.63 99.1 8.75 98.8 8.88 98.8 9.13
32.0 30.5 107.3 8.48 107.3 8.71 107.0 9.05 107.0 9.06 106.6 9.17 106.6 9.40
37.5 36.0 115.9 8.79 115.6 9.01 115.6 9.22 115.2 9.33 115.2 9.44 112.8 9.38
41.0 40.0 121.7 8.99 121.4 9.19 121.4 9.39 121.0 9.50 121.0 9.60 112.8 8.81
45.0 43.0 127.9 9.17 127.9 9.36 127.6 9.56 125.5 9.42 121.4 9.04 112.8 8.29
48.0 46.0 134.4 9.35 134.1 9.54 129.6 9.22 125.5 8.85 121.4 8.50 112.8 7.80
52.0 50.0 141.3 9.52 137.8 9.35 129.6 8.67 125.5 8.33 121.4 8.00 112.8 7.35
55.0 53.0 146.4 9.42 137.8 8.77 129.6 8.13 125.5 7.82 121.4 7.52 112.8 6.92
59.0 57.0 146.4 8.87 137.8 8.26 129.6 7.67 125.5 7.37 121.4 7.09 112.8 6.53
