103
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
90%
-3.5 -4.0 68.6 7.67 68.2 7.94 68.2 8.21 67.9 8.34 67.9 8.49 67.9 8.75
-2.0 -2.5 69.6 7.75 69.6 8.03 69.3 8.29 69.3 8.43 69.3 8.56 68.9 8.82
2.0 1.5 72.4 7.95 72.0 8.20 72.0 8.46 72.0 8.59 71.7 8.71 71.7 8.97
7.0 5.0 75.4 8.14 75.1 8.38 75.1 8.63 74.8 8.67 74.8 8.87 74.8 9.12
11.0 8.5 78.5 8.33 78.5 8.57 78.2 8.80 78.2 8.93 78.2 9.04 77.8 9.27
14.5 12.0 82.3 8.53 82.3 8.75 82.0 8.98 82.0 9.10 82.0 9.21 81.6 9.44
15.0 14.0 84.4 8.63 84.0 8.85 84.0 9.07 83.7 9.18 83.7 9.29 83.7 9.51
17.0 16.0 86.1 8.72 86.1 8.94 85.7 9.15 85.7 9.25 85.7 9.36 84.7 9.46
19.5 18.0 89.2 8.86 89.2 9.07 88.8 9.28 88.8 9.38 88.8 9.49 84.7 9.03
23.0 22.0 94.0 9.06 93.6 9.25 93.6 9.45 93.6 9.55 90.9 9.25 84.7 8.49
26.5 25.0 98.4 9.23 98.4 8.39 97.4 9.46 94.0 9.08 90.9 8.71 84.7 8.00
32.0 30.5 106.6 9.50 103.6 8.24 97.4 8.58 94.0 8.24 90.9 7.92 84.7 7.27
37.5 36.0 109.7 9.05 103.6 8.43 97.4 7.81 94.0 7.52 90.9 7.22 84.7 6.65
41.0 40.0 109.7 8.51 103.6 7.93 97.4 7.36 94.0 7.08 90.9 6.81 84.7 6.27
45.0 43.0 109.7 8.00 103.6 7.47 97.4 6.94 94.0 6.68 90.9 6.43 84.7 5.93
48.0 46.0 109.7 7.54 103.6 7.03 97.4 6.54 94.0 6.30 90.9 6.07 84.7 5.60
52.0 50.0 109.7 7.10 103.6 6.63 97.4 6.18 94.0 5.96 90.9 5.73 84.7 5.30
55.0 53.0 109.7 6.68 103.6 6.25 97.4 5.82 94.0 5.62 90.9 5.42 84.7 5.01
59.0 57.0 109.7 6.31 103.6 5.91 97.4 5.52 94.0 5.30 90.9 5.13 84.7 4.75
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
80%
-3.5 -4.0 68.2 8.20 67.9 8.44 67.9 8.68 67.9 8.80 67.6 8.93 67.6 9.16
-2.0 -2.5 69.3 8.27 69.3 8.52 68.9 8.75 68.9 8.87 68.9 8.99 68.6 9.23
2.0 1.5 72.0 8.45 71.7 8.67 71.7 8.90 71.7 9.02 71.7 9.13 71.3 9.35
7.0 5.0 75.1 8.62 74.8 8.83 74.8 9.06 74.8 9.16 74.4 9.27 74.4 9.50
11.0 8.5 78.2 8.79 78.2 9.01 77.8 9.21 77.8 9.31 77.8 9.42 75.4 9.17
14.5 12.0 82.0 8.97 82.0 9.17 81.6 9.37 81.6 9.47 80.9 9.45 75.4 8.66
15.0 14.0 84.0 9.06 83.7 9.25 83.7 9.45 83.7 9.55 80.9 9.17 75.4 8.40
17.0 16.0 85.7 9.14 85.7 9.33 85.4 9.52 83.7 9.31 80.9 8.93 75.4 8.18
19.5 18.0 88.8 9.27 88.8 9.46 86.4 9.25 83.7 8.88 80.9 8.53 75.4 7.85
23.0 22.0 93.6 8.42 91.9 9.38 86.4 8.69 83.7 8.35 80.9 8.02 75.4 7.36
26.5 25.0 97.4 8.47 91.9 8.83 86.4 8.18 83.7 7.91 80.9 7.56 75.4 6.96
32.0 30.5 97.4 8.61 91.9 8.02 86.4 7.45 83.7 7.17 80.9 6.89 75.4 6.34
37.5 36.0 97.4 7.84 91.9 7.31 86.4 6.80 83.7 6.55 80.9 6.30 75.4 5.81
41.0 40.0 97.4 7.38 91.9 6.90 86.4 6.42 83.7 6.18 80.9 5.96 75.4 5.50
45.0 43.0 97.4 6.96 91.9 6.52 86.4 6.06 83.7 5.84 80.9 5.63 75.4 5.20
48.0 46.0 97.4 6.57 91.9 6.14 86.4 5.75 83.7 5.52 80.9 5.32 75.4 4.93
52.0 50.0 97.4 6.20 91.9 5.80 86.4 5.42 83.7 5.22 80.9 5.04 75.4 4.67
55.0 53.0 97.4 5.84 91.9 5.48 86.4 5.12 83.7 4.94 80.9 4.76 75.4 4.42
59.0 57.0 97.4 5.53 91.9 5.19 86.4 4.86 83.7 4.68 80.9 4.52 75.4 4.20
