105
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
50%
-3.5 -4.0 61.0 8.43 57.6 7.84 54.2 7.28 52.1 7.02 50.4 6.74 47.0 6.21
-2.0 -2.5 61.0 8.24 57.6 7.68 54.2 7.14 52.1 6.86 50.4 6.60 47.0 6.09
2.0 1.5 61.0 7.86 57.6 7.33 54.2 6.82 52.1 6.57 50.4 6.32 47.0 5.83
7.0 5.0 61.0 7.49 57.6 6.99 54.2 6.50 52.1 6.26 50.4 6.03 47.0 5.57
11.0 8.5 61.0 7.11 57.6 6.65 54.2 6.18 52.1 5.96 50.4 5.73 47.0 5.30
14.5 12.0 61.0 6.73 57.6 6.29 54.2 5.87 52.1 5.65 50.4 5.45 47.0 5.04
15.0 14.0 61.0 6.55 57.6 6.12 54.2 5.71 52.1 5.51 50.4 5.30 47.0 4.91
17.0 16.0 61.0 6.39 57.6 5.98 54.2 5.57 52.1 5.38 50.4 5.18 47.0 4.79
19.5 18.0 61.0 6.12 57.6 5.75 54.2 5.34 52.1 5.16 50.4 4.98 47.0 4.61
23.0 22.0 61.0 5.77 57.6 5.42 54.2 5.06 52.1 4.89 50.4 4.71 47.0 4.37
26.5 25.0 61.0 5.47 57.6 5.13 54.2 4.79 52.1 4.63 50.4 4.47 47.0 4.15
32.0 30.5 61.0 5.02 57.6 4.71 54.2 4.42 52.1 4.26 50.4 4.12 47.0 3.84
37.5 36.0 61.0 4.62 57.6 4.35 54.2 4.07 52.1 3.94 50.4 3.81 47.0 3.55
41.0 40.0 61.0 4.39 57.6 4.12 54.2 3.87 52.1 3.74 50.4 3.62 47.0 3.38
45.0 43.0 61.0 4.16 57.6 3.92 54.2 3.68 52.1 3.56 50.4 3.45 47.0 3.22
48.0 46.0 61.0 3.95 57.6 3.72 54.2 3.50 52.1 3.40 50.4 3.28 47.0 3.07
52.0 50.0 61.0 3.75 57.6 3.54 54.2 3.34 52.1 3.23 50.4 3.13 47.0 2.93
55.0 53.0 61.0 3.57 57.6 3.37 54.2 3.17 52.1 3.08 50.4 2.98 47.0 2.79
59.0 57.0 61.0 3.40 57.6 3.21 54.2 3.03 52.1 2.94 50.4 2.85 47.0 2.66
GMV- Q120WM/B-U(U)
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
130%
-3.5 -4.0 87.4 7.36 87.0 7.88 86.6 8.40 86.6 8.66 86.1 8.92 86.1 9.45
-2.0 -2.5 88.7 7.52 88.3 8.04 88.3 8.55 87.9 8.81 87.9 9.05 87.4 9.57
2.0 1.5 92.1 7.88 91.7 8.36 91.3 8.86 91.3 9.07 91.3 9.35 90.9 9.85
7.0 5.0 96.0 8.24 95.6 8.71 95.1 9.19 95.1 9.42 94.7 9.66 94.7 10.14
11.0 8.5 99.9 8.61 99.9 9.07 99.4 9.51 99.0 9.74 99.0 9.97 98.6 10.42
14.5 12.0 104.6 8.99 104.1 9.42 103.7 9.85 103.7 10.07 103.7 10.28 103.3 10.72
15.0 14.0 107.1 9.18 106.7 9.59 106.3 10.01 106.3 10.23 105.9 10.43 105.9 10.85
17.0 16.0 109.3 9.34 108.9 9.74 108.9 10.16 108.4 10.37 108.4 10.57 108.0 10.99
19.5 18.0 113.1 9.61 113.1 10.01 112.7 10.41 112.7 10.61 112.3 10.80 111.9 11.20
23.0 22.0 119.1 9.97 118.7 10.15 118.3 10.73 118.3 10.92 117.9 11.10 117.9 11.48
26.5 25.0 124.7 10.30 124.3 10.66 124.3 11.02 123.9 11.20 123.9 11.38 123.4 11.73
32.0 30.5 134.6 10.80 134.6 11.14 134.1 11.46 134.1 11.62 133.7 11.80 133.7 12.13
37.5 36.0 145.3 11.25 144.9 11.56 144.4 11.87 144.4 12.02 144.4 12.18 144.0 12.48
41.0 40.0 152.6 11.53 152.1 11.83 152.1 12.11 151.7 12.26 151.7 12.41 151.3 12.69
45.0 43.0 160.3 11.80 159.9 12.07 159.9 12.36 159.4 11.14 159.4 12.63 153.0 12.13
48.0 46.0 168.4 12.04 168.0 12.31 168.0 12.57 167.6 12.71 164.1 12.45 153.0 11.39
52.0 50.0 177.0 12.29 176.6 12.53 175.7 12.69 169.7 12.19 164.1 11.69 153.0 10.73
55.0 53.0 186.4 12.52 186.0 12.76 175.7 11.90 169.7 11.42 164.1 10.97 153.0 10.07
59.0 57.0 195.4 12.73 186.9 12.08 175.7 11.20 169.7 10.77 164.1 10.34 153.0 9.50
