107
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
100%
-3.5 -4.0 86.1 9.47 85.7 9.87 85.7 10.27 85.3 10.47 85.3 10.66 84.9 11.07
-2.0 -2.5 87.4 9.59 87.4 9.99 87.0 10.38 87.0 10.58 86.6 10.79 86.6 11.18
2.0 1.5 90.9 9.87 90.4 10.24 90.4 10.62 90.4 10.81 90.0 11.00 90.0 11.38
7.0 5.0 94.7 10.15 94.3 10.51 94.3 10.88 93.9 11.07 93.9 11.25 93.4 11.61
11.0 8.5 98.6 10.45 98.6 10.79 98.1 11.14 98.1 11.31 98.1 11.08 97.7 11.84
14.5 12.0 103.3 10.73 102.9 11.07 102.9 11.39 102.9 11.57 102.4 11.73 102.4 12.06
15.0 14.0 105.9 10.88 105.4 11.20 105.4 11.53 105.0 11.69 105.0 11.85 104.6 12.18
17.0 16.0 108.0 11.00 108.0 11.33 107.6 11.64 107.6 11.80 107.1 11.96 107.1 12.27
19.5 18.0 111.9 11.22 111.9 11.53 111.4 11.83 111.4 11.99 111.4 12.14 111.0 12.45
23.0 22.0 117.9 11.50 117.4 11.79 117.4 12.08 117.0 12.23 117.0 12.37 117.0 12.67
26.5 25.0 123.4 11.76 123.4 12.03 123.0 12.31 123.0 12.45 123.0 12.59 117.9 12.06
32.0 30.5 133.3 12.15 133.3 12.40 132.9 12.65 130.7 12.45 126.4 11.94 117.9 10.96
37.5 36.0 144.0 12.49 143.6 12.72 135.0 11.77 130.7 11.31 126.4 10.87 117.9 9.97
41.0 40.0 151.3 12.72 143.6 11.95 135.0 11.07 130.7 10.65 126.4 10.23 117.9 9.41
45.0 43.0 152.1 12.07 143.6 11.23 135.0 10.42 130.7 10.03 126.4 9.64 117.9 8.86
48.0 46.0 152.1 11.34 143.6 10.57 135.0 9.81 130.7 9.45 126.4 9.08 117.9 8.36
52.0 50.0 152.1 10.68 143.6 9.96 135.0 9.26 130.7 8.90 126.4 8.57 117.9 7.90
55.0 53.0 152.1 10.03 143.6 9.36 135.0 8.71 130.7 8.39 126.4 8.08 117.9 7.46
59.0 57.0 152.1 9.46 143.6 8.84 135.0 8.23 130.7 7.93 126.4 7.63 117.9 7.06
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
90%
-3.5 -4.0 85.7 10.18 85.3 10.53 85.3 10.89 84.9 11.07 84.9 11.26 84.9 11.61
-2.0 -2.5 87.0 10.28 87.0 10.65 86.6 11.00 86.6 11.18 86.6 11.35 86.1 11.71
2.0 1.5 90.4 10.54 90.0 10.88 90.0 11.22 90.0 11.39 89.6 11.56 89.6 11.90
7.0 5.0 94.3 10.80 93.9 11.12 93.9 11.45 93.4 11.50 93.4 11.77 93.4 12.10
11.0 8.5 98.1 11.06 98.1 11.37 97.7 11.68 97.7 11.84 97.7 11.99 97.3 12.30
14.5 12.0 102.9 11.31 102.9 11.61 102.4 11.91 102.4 12.07 102.4 12.22 102.0 12.52
15.0 14.0 105.4 11.45 105.0 11.75 105.0 12.03 104.6 12.18 104.6 12.33 104.6 12.61
17.0 16.0 107.6 11.57 107.6 11.85 107.1 12.14 107.1 12.27 107.1 12.42 105.9 12.54
19.5 18.0 111.4 11.76 111.4 12.03 111.0 12.31 111.0 12.45 111.0 12.59 105.9 11.98
23.0 22.0 117.4 12.02 117.0 12.27 117.0 12.53 117.0 12.67 113.6 12.27 105.9 11.26
26.5 25.0 123.0 12.25 123.0 11.14 121.7 12.54 117.4 12.04 113.6 11.56 105.9 10.61
32.0 30.5 133.3 12.60 129.4 10.93 121.7 11.38 117.4 10.93 113.6 10.50 105.9 9.65
37.5 36.0 137.1 12.00 129.4 11.18 121.7 10.37 117.4 9.97 113.6 9.58 105.9 8.82
41.0 40.0 137.1 11.29 129.4 10.51 121.7 9.77 117.4 9.39 113.6 9.04 105.9 8.32
45.0 43.0 137.1 10.61 129.4 9.91 121.7 9.20 117.4 8.86 113.6 8.53 105.9 7.86
48.0 46.0 137.1 10.00 129.4 9.32 121.7 8.67 117.4 8.36 113.6 8.05 105.9 7.43
52.0 50.0 137.1 9.42 129.4 8.80 121.7 8.20 117.4 7.90 113.6 7.61 105.9 7.04
55.0 53.0 137.1 8.86 129.4 8.30 121.7 7.73 117.4 7.46 113.6 7.19 105.9 6.64
59.0 57.0 137.1 8.38 129.4 7.84 121.7 7.32 117.4 7.04 113.6 6.81 105.9 6.31
