75
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
110%
-3.5 -4.0 103.9 10.77 103.4 11.30 102.9 11.85 102.9 12.12 102.9 12.38 102.3 12.93
-2.0 -2.5 105.4 10.94 105.4 11.47 104.9 12.00 104.9 12.27 104.4 12.53 104.4 13.07
2.0 1.5 109.5 11.30 109.0 11.82 109.0 12.33 108.5 12.58 108.5 12.85 108.0 13.35
7.0 5.0 114.2 11.69 113.7 12.18 113.1 12.67 113.1 12.92 113.1 13.17 112.6 13.65
11.0 8.5 118.8 12.08 118.8 12.55 118.3 13.02 118.3 13.25 117.8 13.48 117.8 13.96
14.5 12.0 124.5 12.47 123.9 12.92 123.9 13.36 123.4 13.60 123.4 13.81 123.4 14.26
15.0 14.0 127.5 12.67 127.0 13.10 126.5 13.55 126.5 13.76 126.5 13.98 126.0 14.41
17.0 16.0 130.1 12.83 129.6 13.27 129.6 13.70 129.6 13.91 129.1 14.13 129.1 14.55
19.5 18.0 134.7 13.13 134.7 13.53 134.2 13.95 134.2 14.16 135.8 14.36 133.7 14.78
23.0 22.0 141.9 13.50 141.4 13.90 140.9 14.28 140.9 14.48 147.6 14.68 140.4 15.08
26.5 25.0 148.6 13.85 148.6 14.21 148.1 14.59 148.1 14.78 159.9 14.96 147.6 15.34
32.0 30.5 160.5 14.36 160.5 14.71 159.9 15.06 159.9 15.23 166.6 15.41 155.3 15.11
37.5 36.0 173.3 14.84 172.8 15.16 172.8 15.48 172.3 15.63 166.6 14.99 155.3 13.75
41.0 40.0 182.1 15.13 182.1 15.44 178.5 15.29 172.3 14.68 166.6 14.10 155.3 12.93
45.0 43.0 191.3 15.41 189.8 15.51 178.5 14.36 172.3 13.80 166.6 13.25 155.3 12.17
48.0 46.0 201.1 15.66 189.8 14.58 178.5 13.51 172.3 12.98 166.6 12.47 155.3 11.47
52.0 50.0 201.1 14.73 189.8 13.71 178.5 12.72 172.3 12.23 166.6 11.75 155.3 10.82
55.0 53.0 201.1 13.81 189.8 12.87 178.5 11.95 172.3 11.50 166.6 11.05 155.3 10.19
59.0 57.0 201.1 13.02 189.8 12.13 178.5 11.29 172.3 10.85 166.6 10.46 155.3 9.64
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
100%
-3.5 -4.0 103.4 11.64 102.9 12.12 102.9 12.62 102.3 12.87 102.3 13.10 101.8 13.60
-2.0 -2.5 104.9 11.79 104.9 12.27 104.4 12.75 104.4 13.00 103.9 13.25 103.9 13.73
2.0 1.5 109.0 12.12 108.5 12.58 108.5 13.05 108.5 13.28 108.0 13.51 108.0 13.98
7.0 5.0 113.7 12.47 113.1 12.92 113.1 13.36 112.6 13.60 112.6 13.81 112.1 14.26
11.0 8.5 118.3 12.83 118.3 13.25 117.8 13.68 117.8 13.90 117.8 13.61 117.3 14.55
14.5 12.0 123.9 13.18 123.4 13.60 123.4 14.00 123.4 14.21 122.9 14.41 122.9 14.81
15.0 14.0 127.0 13.36 126.5 13.76 126.5 14.16 126.0 14.36 126.0 14.56 125.5 14.96
17.0 16.0 129.6 13.51 129.6 13.91 129.1 14.30 129.1 14.50 128.6 14.69 128.6 15.08
19.5 18.0 134.2 13.78 134.2 14.16 133.7 14.53 133.7 14.73 133.7 14.91 133.2 15.29
23.0 22.0 141.4 14.13 140.9 14.48 140.9 14.84 140.4 15.03 140.4 15.19 140.4 15.56
26.5 25.0 148.1 14.45 148.1 14.78 147.6 15.13 147.6 15.29 147.6 15.46 141.4 14.81
32.0 30.5 159.9 14.93 159.9 15.23 159.4 15.54 156.9 15.29 151.7 14.66 141.4 13.46
37.5 36.0 172.8 15.34 172.3 15.63 162.0 14.46 156.9 13.90 151.7 13.35 141.4 12.25
41.0 40.0 181.5 15.63 172.3 14.68 162.0 13.60 156.9 13.08 151.7 12.57 141.4 11.55
45.0 43.0 182.6 14.83 172.3 13.80 162.0 12.80 156.9 12.32 151.7 11.84 141.4 10.89
48.0 46.0 182.6 13.93 172.3 12.98 162.0 12.05 156.9 11.60 151.7 11.15 141.4 10.27
52.0 50.0 182.6 13.12 172.3 12.23 162.0 11.37 156.9 10.94 151.7 10.52 141.4 9.71
55.0 53.0 182.6 12.32 172.3 11.50 162.0 10.71 156.9 10.31 151.7 9.92 141.4 9.16
59.0 57.0 182.6 11.62 172.3 10.85 162.0 10.11 156.9 9.74 151.7 9.38 141.4 8.68
