97
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
120%
-3.5 -4.0 52.2 4.49 51.9 4.75 51.7 5.02 51.7 5.15 51.7 5.29 51.4 5.56
-2.0 -2.5 53.0 4.57 52.7 4.84 52.7 5.05 52.5 5.23 52.5 5.36 52.2 5.63
2.0 1.5 55.0 4.75 54.8 5.01 54.8 5.26 54.5 5.39 54.5 5.51 54.3 5.76
7.0 5.0 57.3 4.94 57.1 5.18 56.8 5.42 56.8 5.55 56.8 5.67 56.6 5.91
11.0 8.5 59.6 5.13 59.6 5.36 59.4 5.60 59.4 5.72 59.1 5.83 59.1 6.06
14.5 12.0 62.5 5.33 62.2 5.54 62.2 5.77 62.0 5.88 62.0 5.99 61.7 6.22
15.0 14.0 64.0 5.42 63.8 5.64 63.5 5.85 63.5 5.97 63.5 6.03 63.2 6.29
17.0 16.0 65.3 5.51 65.0 5.72 65.0 5.93 64.8 6.03 64.8 6.15 64.5 6.36
19.5 18.0 67.6 5.65 67.6 5.85 67.4 6.06 67.4 6.16 67.1 6.26 67.1 6.46
23.0 22.0 71.2 5.83 71.0 6.03 70.7 6.22 70.7 6.32 70.7 6.42 70.4 6.61
26.5 25.0 74.6 6.00 74.6 6.19 74.3 6.37 74.3 6.46 74.0 6.56 74.0 6.74
32.0 30.5 80.5 6.26 80.5 6.43 80.2 6.68 80.2 6.69 80.0 6.77 80.0 6.94
37.5 36.0 86.9 6.49 86.6 6.65 86.6 6.81 86.4 6.89 86.4 6.97 84.6 6.93
41.0 40.0 91.3 6.64 91.0 6.79 91.0 6.94 90.8 7.01 90.8 7.09 84.6 6.51
45.0 43.0 95.9 6.77 95.9 6.91 95.6 7.06 94.1 6.96 91.0 6.67 84.6 6.12
48.0 46.0 100.8 6.91 100.5 7.04 97.2 6.81 94.1 6.54 91.0 6.27 84.6 5.76
52.0 50.0 105.9 7.03 103.4 6.91 97.2 6.40 94.1 6.15 91.0 5.91 84.6 5.43
55.0 53.0 109.8 6.96 103.4 6.48 97.2 6.00 94.1 5.78 91.0 5.55 84.6 5.11
59.0 57.0 109.8 6.55 103.4 6.10 97.2 5.66 94.1 5.45 91.0 5.24 84.6 4.82
Combination
Outdoor air temp.
Indoor air temperature
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
℉
DB
℉
WB KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW KBtu/h kW
110%
-3.5 -4.0 51.9 4.88 51.7 5.12 51.4 5.37 51.4 5.49 51.4 5.61 51.2 5.86
-2.0 -2.5 52.7 4.96 52.7 5.20 52.5 5.44 52.5 5.56 52.2 5.68 52.2 5.92
2.0 1.5 54.8 5.12 54.5 5.36 54.5 5.59 54.3 5.70 54.3 5.82 54.0 6.05
7.0 5.0 57.1 5.30 56.8 5.52 56.6 5.74 56.6 5.85 56.6 5.97 56.3 6.18
11.0 8.5 59.4 5.48 59.4 5.69 59.1 5.90 59.1 6.00 58.9 6.11 58.9 6.33
14.5 12.0 62.2 5.65 62.0 5.85 62.0 6.06 61.7 6.16 61.7 6.26 61.7 6.46
15.0 14.0 63.8 5.74 63.5 5.94 63.2 6.14 63.2 6.24 63.2 6.33 63.0 6.53
17.0 16.0 65.0 5.82 64.8 6.01 64.8 6.21 64.8 6.30 64.5 6.40 64.5 6.59
19.5 18.0 67.4 5.95 67.4 6.13 67.1 6.32 67.1 6.42 67.9 6.51 66.8 6.70
23.0 22.0 71.0 6.12 70.7 6.30 70.4 6.47 70.4 6.56 73.8 6.65 70.2 6.83
26.5 25.0 74.3 6.27 74.3 6.44 74.0 6.61 74.0 6.70 80.0 6.78 73.8 6.95
32.0 30.5 80.2 6.51 80.2 6.67 80.0 6.82 80.0 6.90 83.3 6.98 77.6 6.85
37.5 36.0 86.6 6.73 86.4 6.87 86.4 7.01 86.1 7.08 83.3 6.79 77.6 6.23
41.0 40.0 91.0 6.85 91.0 7.00 89.2 6.93 86.1 6.65 83.3 6.39 77.6 5.86
45.0 43.0 95.6 6.98 94.9 7.03 89.2 6.51 86.1 6.25 83.3 6.00 77.6 5.51
48.0 46.0 100.5 7.10 94.9 6.61 89.2 6.12 86.1 5.88 83.3 5.65 77.6 5.20
52.0 50.0 100.5 6.67 94.9 6.21 89.2 5.76 86.1 5.54 83.3 5.33 77.6 4.90
55.0 53.0 100.5 6.26 94.9 5.83 89.2 5.42 86.1 5.21 83.3 5.01 77.6 4.62
59.0 57.0 100.5 5.90 94.9 5.50 89.2 5.11 86.1 4.92 83.3 4.74 77.6 4.37
