Gree GMV6 Series User Manual

Gree GMV6 DC Inverter VRF Units Service Manual
306
No.
Name
Material code
Vulnerable part *
Qty
22
Electronic Expansion Valve
43044100172
*
1
23
Bidirection Strainer
07220016
*
1
24
Gas Tube Filter
072190511
*
1
25
Electromagnetic Valve
43044100224
*
1
26
Base Plate Sub-Assy
017000060119P
1
27
Oil Separator
035028060002
*
1
28
Cut off Valve
0733410005301
*
1
29
Cut off Valve
0733410001401
*
1
30
Electromagnetic Valve
072008000005
*
2
31
Strainer
07222025
*
1
32
Gas-liquid Separator
035027060004
*
1
33
Nozzle for Adding Freon
06130002
*
1
34
Transformer
43118000023
*
1
35
Cover Plate
012035000246P
1
36
Front Panel Assy
000003060148
1
37
Left Front Panel
012062000016P
1
38
right panel
012167000014P
1
39
Magnet Coil (electromagnetic valve)
072001060006
*
1
40
4 Way Valve Coil
072010060002
*
1
41
Magnet Coil (electromagnetic valve)
07200106000811
*
1
42
Magnet Coil (electromagnetic valve)
072001060007
*
1
43
Magnet Coil (electromagnetic valve)
07200106000812
*
1
44
Electric Expand Valve Fitting
072002000011
*
1
45
Electric Expand Valve Fitting
4304413264
*
1
46
Electric Expand Valve Fitting
4304413274
*
1
47
Electric Heater(Compressor)
7651540714
*
1
48
Pressure Sensor
32210103
*
1
49
Pressure Sensor
32218000008
*
1
50
Sensor Sub-assy
390002060037
*
1
51
Compressor and Fittings
009001060575
*
1
52
Pressure Protect Switch
4602000911
*
1
53
Right Side Plate Sub-Assy
017038060026P
1
54
Electric Box Assy
100002071693
*
1
55
Terminal Board
42200006000303
*
1
56
Terminal Board
42200006005403
*
1
57
Main Board
300027061456
*
1
58
Filter Board
300020060004
*
1
59
Main Board
300027060023
*
1
60
Main Board
300027000583
*
2
61
Reactor
450004060005
*
1
62
Radiator
4901800008801
*
1
Above data is subject to change without notice,pls reference the SP in global service website.
